For additional connection diagrams for all UPG equipment refer to "Low Voltage System Wiring" document available online at www.upgnet.com in the
Product Catalog Section.
HP 2C Single Stage Heat Pump – Single Stage PSC Furnace
THERMOSTAT THERMOSTAT
*BP21H50124
*BN21H00124
*DN22U00124
*DP21H40124
*DN21H00124
N/A
FIGURE 7: Thermostat Chart - Single Stage Heat Pump – Single Stage PSC Furnaces

Johnson Controls Unitary Products

THERMOSTAT
*DP32H70124
C
24 – Volt Common
Y1
First Stage Compressor
R
24 – Volt Hot
G
Fan
E
Emergency Heat
W2
N/A
Third Stage Heat
O
Reversing Valve
Energized in Cool
L
Malfunction Light
Y2
Second Stage Compressor
W1
Second Stage Aux. Heat
3
External Humidistat
(Optional)
Open on Humidity Rise
24VAC Humidifier
(Optional)
Step 1 of Thermostat
Installer / Configuration
Menu must be set to
Heat Pump 1
Step 9 of Thermostat
Installer / Configuration
Menu must be set to
Pump OFF
3
Part Number:
S1-2HU16700124
ID MODELS
G*(8/9)S GF(8/9)
G*9F LF8
L(Y/M)8S TG(8/9)S
G8C (G/T)GLS
SINGLE STAGE
PSC
FURNACE
SINGLE STAGE PSC 2
FURNACE
C
24 – Volt Common
Y/Y2
Full Stage Compressor
R
24 – Volt Hot
G
Fan
W
Full Stage Heat
Other Part Numbers:
2
SAP = Legacy
265901 = 031-09166
359513-UIM-A-0408
OD MODELS
E*R* *RHS
E*ZD HP*
E*B* *HGD
SINGLE STAGE
HEAT PUMP
DEMAND DEFROST 1
CONTROL
C
24 – Volt Common
Y
Compressor
R
24 – Volt Hot
W1/66(out)
Heat
O
Reversing Valve
Energized in Cool
X/L
Malfunction Light
W
Auxiliary Heat
Part Numbers:
1
SAP = Legacy
67297 = 031-01975
7
