This Heat Pump has been specially developed and built as a heat pump
to meet the dual needs of heating and cooling. It's not just an air condi-
tioner with extra parts. That's why you can rely on efficient, trouble-free
operation.
Your system is fully automatic. Set the thermostat and forget it. And it's
automatically protected from damage by voltage fluctuations or exces-
sive heating or cooling demands.
Your split system heat pump consists of two units - one installed out-
doors and one installed indoors. The indoor unit may be installed in a
basement, attic, or crawl space.
HOW YOUR HEAT PUMP WORKS
If your hand is wet and you blow on it, it feels cool because some of the
moisture is evaporating and becoming a vapor. This process requires
heat. The heat is being taken from your hand, so your hand feels cool.
That's what happens with a heat pump. During the cooling cycle, your
system will remove heat and humidity from your home and will transfer
this heat to the outdoor air.
During the heating cycle, your system will remove heat and humidity
from the outdoor air and will transfer this heat to your home. This is pos-
sible because even 0°F outdoor air contains a great deal of heat.
Remember that your heat pump doesn't generate much heat, it merely
transfers it from one place to another.
SYSTEM OPERATION
Your thermostat puts full control of the comfort level in your home at
your fingertips. DO NOT switch your thermostat rapidly ON and OFF or
between HEAT to COOL. This could damage your equipment. Always
allow at least 5 minutes between changes.
TABLE OF CONTENTS
FILTER CARE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
OUTDOOR UNIT FINISH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
CLEARANCES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
POWER INTERRUPTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Heating Season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Cooling Season . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
SERVICE CALLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
PARTS INFORMATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
CHARACTERISTICS OF HEAT PUMPS . . . . . . . . . . . . . . . . . . . . . . .3
A CONSTANT HEAT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
WATER RUN-OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
OUTDOOR COIL DEFROSTING . . . . . . . . . . . . . . . . . . . . . . . . . . .3
LIMITED WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Johnson Controls Unitary Products
Consumer Relations
5005 York Drive
Norman, OK 73069
SETTING THE THERMOSTAT
Although thermostats may vary widely in appearance, they are all
designed to perform the same basic function: to control the operation of
your air conditioning or heat pump system. Regardless of size or shape,
each thermostat will feature a temperature indicator; a dial, arm, or
push button for selection of the desired temperature; a fan switch to
choose the indoor fan operation; and a comfort switch for you to select
the system mode of operation.
Only approved thermostats have been tested and are fully compatible
with this equipment. Please be aware that many different thermostats
operate on batteries or "power stealing" principals. These types of ther-
mostats can not be supported as trouble free when used with this product.
A complete operating instruction is provided by the manufacturer for
each thermostat. Familiarize yourself with its proper operation to obtain
the maximum comfort with minimum energy consumption.
If your system has been designed to allow both cooling and heating
operation, you may have either a manual change-over type, or a pro-
grammable electronic type thermostat.
Manual change-over simply means that the comfort switch must be
manually positioned every time you wish to switch from the cooling to
heating or heating to cooling modes of operation.
The computerized electronic thermostat is actually a sophisticated elec-
tronic version of a manual change-over type. This thermostat includes
features which allow "set-back" temperature variations for periods of
sleep, or while you are away during the day, and means energy savings
for you. The thermostat also features a digital clock.
