Summary of Contents for Qtx FH-1500
- Page 1 FH-1500 FOG/HAZE MACHINE Item ref: 160.465UK User Manual...
- Page 2 To prevent risk of fire or electric shock, do not expose electrical parts to rain or moisture. If liquids are spilled on areas other than inside the fluid tank, disconnect the mains, allow the FH-1500 to dry out and have it checked by qualified personnel before further use.
-
Page 3: Rear Panel
Setting up The FH-1500 requires haze fluid to create the effect. It is recommended to use one from the range of qtx haze fluids for best results. A chart for recommended fluids is included further along in this document. ... -
Page 4: Wireless Remote Control
You may now press the Manual (3) button for haze on demand – releasing button stops the haze effect When the ready indicator is off, the FH-1500 needs time to re-heat and will not produce haze effect For constant haze effect, use the latching Continuous (2) button and the Continuous LED (6) will light ... -
Page 5: Specifications
Specifications Power supply 230Vac, 50Hz (IEC) Haze output (approx.) 11,500 CU Ft (325m³) / min Fuse rating F8A (20mm glass) Reheat time 7 - 8 mins (approx) Tank capacity 2.0l Heating element 1500W Remote control Wireless remote, wired timer remote, DMX512 Remote control frequency 433MHz DMX channels... - Page 6 160.465UK User Manual...
