Qtx QTFX-900 mkII User Manual

Download this manual

QTFX-900 mkII

Item ref: 160.463UK

User Manual

Fog Machine

Page 1 QTFX-900 mkII Item ref: 160.463UK User Manual Fog Machine...
Page 2 Refer all servicing to qualified service personnel. Placement The QTFX-900 mkII has a built-in fluid tank and should be operated in an upright position. If free-standing, ensure that the QTFX-900 mkII is positioned on a stable, non-slip surface. If mounted at height, use the integral bracket and it is advisable to add a safety cable.
Page 3 Setting up and operation The QTFX-900 mkII requires fog fluid to produce the effect. It is recommended to use one of the range of qtx fog fluids for best results. A chart for recommended fog fluids is included further along in this document ...
Page 4: Wired Remote Control
When the machine is ready to operate, the light on the remote control will illuminate. You may now press the button for fog on demand.  When the remote control light is off, the QTFX-900 mkII needs time to re-heat. Do not attempt to produce fog until the light is lit. RF remote control...
Page 5: Specifications
Specifications Power supply 230Vac, 50Hz (IEC) Power 900W Reheat time 4 min (approx.) Fog output (approx.) 10,000 Cu Ft (283m³) / min Tank capacity 1.3l Remote control frequency 433MHz Dimensions 235 x 180 x 111mm Weight 4.05kg Troubleshooting Warning: Hot components! ... Switch off and allow to cool before touching the unit. Check mains voltage is correct and socket is switched on Check IEC lead is OK and connected properly No light on mains switch...
Page 6 160.463UK User Manual...
