Microh QUADBEAM Owner's Manual

4 head - red and green 260mw laser light
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Owner's Manual
4 Head - Red and Green 260mw Laser Light
PLEASE READ INSTRUCTION MANUAL BEFORE USING THE PRODUCT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QUADBEAM and is the answer not in the manual?

Questions and answers

Related Manuals for Microh QUADBEAM

Summary of Contents for Microh QUADBEAM

  • Page 1 Owner’s Manual 4 Head - Red and Green 260mw Laser Light PLEASE READ INSTRUCTION MANUAL BEFORE USING THE PRODUCT...
  • Page 2 When you receive this product, please check for any problems caused during shipping. Please ensure that the following parts are included in this package: • QUADBEAM/RG – 1 pc • DMX512 (XLR) signal cable – 1 pc • Power Cable – 1 pc •...
  • Page 3 NOTICE Please follow the instructions outlined in this manual. This product must be repaired by a qualified person. • Do not operate this product in wet or dusty conditions. • This unit must be installed in a fixed position in order to minimize vibrations.

  • Page 4: Dmx Operation

    DMX Operation This light can be controlled using standard DMX512 controllers. In order to control the light via DMX you must assign the DMX address using the 10 dip switches at the back of the unit. To put the unit into DMX Mode, dip switch 10 must be set to the off position. After doing this, you must then select the desired DMX Address by using dip switches 1 to 9.
  • Page 5 SLIDE CHANNEL Control content VALUE 0~50 Black Out – Laser Off 51~101 Sound active mode Ch 1 102~152 DMX512 Image mode 1 153~203 DMX512 Image mode 2 204~255 Auto running 0~03 Circle zoom in/out 04~7 Short line rotation 8~11 Circle move around X axis Ch 2 12~15 Circle move around z axis...
  • Page 6 Ch 2 144~147 Small circle trace figure 8 148~151 Dot move right and left 152~155 Dot move around one path 156~159 Image flow like wave 160~163 Cloud move left and right 164~167 Cloud rotating on Y axis 168~171 Cloud rotating on X axis 172~175 “V”...
  • Page 7 DMX Operation Continued Channel 1 is master DMX Channel. This is used to put the unit in sound active mode, DMX512 Image Mode 1, DMX Image Mode 2, Auto and Blackout. Please see the values in the chart above for desired effect. Channel 2 Control: This channel gives user ability to select the Images.

  • Page 8: Sound Active Mode

    SOUND ACTIVE MODE This unit can be run in Sound Active Mode. In Sound Active Mode the unit will change pattern and movement to the beat of the music. SOUND ACTIVE SETTINGS 1. To select Sound Active Mode, all DMX dip switches should be set to the off position.

This manual is also suitable for:

Quadbeam rg
