  • Page 1 CH805CE-1 - 800mm Touch Control Ceramic Cooktop...
  • Page 3: Table Of Contents

    Built-in ceramic-glass cooktop Dear customer ! The built-in ceramic-glass cooktop is intended for household use only. Materials used for packaging are nature friendly and may be recycled, deposited or destroyed without any threats to the environment. In order to recognize these features, all packing materials are marked with relevant symbols.
  • Page 4: Important Warnings

    Important warnings • The appliance may be built-in and connected to the power supply only by a qualifi ed technician. • Particular areas of the cooktop surface (adjacent to the hotplates) are hot during operation. Prevent the children to hang around the appliance and warn them properly against the danger of burns.
  • Page 5: Ceramic-Glass Cooktop

    Ceramic-glass cooktop 1. Rear left hotplate 2. Front left hotplate 3. Hob control module 4. Front right hotplate 5. Rear right hotplate Control panel A Ceramic hob main switch sensor B Blocked operation sensor B1 Blocked operation control lamp C Extended hotplate ring ON/OFF sensor C1 Second hotplate LED signal lamp (hotplate 4) D Hotplate E Second and third hotplate LED signal lamp (hotplate 2),...
  • Page 6 Ceramic-glass cooktop is equipped with four hotplates designed as cooking zones. The surface of the hob is fl at, without any edges for eventual gathering of dirt. Cookware may easily be moved about along the hob surface. • Hotplates quickly reach the selected heating power while the adjacent area around the hotplates remains cool.
  • Page 7: Energy Saving Tips

    Hotplate may be damaged: • if it is left in operation without any cookware being placed on top, or if covered with empty cookware; • if improper cookware is used: unevenly fl at bottom or small diameter (traditional Turkish coffee kettle). •...
  • Page 8: Glass Ceramic Hob Control Elements

    Glass ceramic hob control elements • Once the glass ceramic hob is connected to the mains (including the power failure), the appliance carries out the harmonization with the conditions of the exterior in order to provide most effi cient sensor function and render the best control environment.
  • Page 9 Switching the hotplates • Once the hob is switched on with the ON/OFF sensor, within the next ten seconds, while the indicators are illuminated, you have to switch on a particular hotplate by touching the (-) or (+) sensors for the selected hotplate and set the desired heating power.
  • Page 10 Power setting Maximum power time (in seconds) Switching the extended • Switch the relevant hotplate ( 2 or 4) and consequently hotplate rings on switch the extended hotplate ring by pressing the relevant (hotplates 2 and 4) sensor (see the control element board illustration). The LED signal lamp above the indicator displays the extended ring is on.
  • Page 11 Switching the hotplate • Particular hotplate is switched off either by pressing the sensor (-) to bring the heating power to “0”, or by simultaneously pressing both the (+) and (-) sensor. Hotplate is switched off automatically after the set timer period elapses. Display indicates “0”...
  • Page 12 Blocking the hob • This function protects the hob from accidental activation operation or change of power level by children or pets. Child lock is activated by pressing the relevant sensor for about 3 seconds, and signaled by the signal LED above the sensor which illuminates for a few seconds.
  • Page 13 Timer controlled period of operation for a particular hotplate • In this mode you are able to select the exact operation time for any hotplate. After the time has elapsed the hotplate automatically turns off. Time may be preset parallel for one hotplate which must be switched on.
  • Page 14 Safety functions and • If both the (+) and (-) sensor are preset together the hotplate is error display switched off. • If all the hotplates indicate the “0” power setting, the hob is switched off after 10 seconds. • If any of the sensors is activated for more than 10 seconds the hob is switched off, the beep sounds, and the indicator displays the fl...
  • Page 15: Cleaning And Maintenance Of Ceramic-Glass Hob

    Cleaning and maintenance of ceramic-glass hob Ceramic glass hob should be cleaned only when completely cooled down, preferably after each use, otherwise even the slightest stains remaining after cooking may burn into the hob surface with each following use. For regular maintenance of ceramic-glass hob use special cleansing agents, produced in such way to create protective fi...
  • Page 16: Connection To The Power Supply

    Connection to the power supply • Connections may be carried out by a qualifi ed technician only. The earthing protection must comply with the standing regulations. • Connection terminals are revealed when the connection box cover is removed. • Prior any attempted connection check that the voltage indicated on the rating plate is in line with your home power supply.
  • Page 17: Mounting The Built-In Cooktop

    Installation diagram NOTE: In some connection boxes the connector bridges are placed between contacts 4 and 5, and in the others they are stored at a designated place within the box. These boxes have the connection screws already in open position so they need not be unscrewed. During the tightening procedure you will hear a faint “click”, meaning that the tightening screw should be fastened tightly all the way.
  • Page 18: Installation Procedure

    the adjacent high kitchen cabinet is 40 mm. • The use of hard wood decorative borders around the worktop behind the appliance is allowed, in case the minimum distance remains as indicated on the installation illustrations. • Minimum distance between the built-in cooktop and rear wall is indicated at the illustration for the installation of the built-in cooktop.
  • Page 19: Technical Information

    Technical information Type CH805CE-1 (SVK72TS) Electrical connection 2N AC 400 V Working voltage 230 V, 50 Hz Type of switch Electronic sensors Cooking zones (ø mm/kW) HL=Hi-light cooking zone Forward left 210/175/120/2,3/HL Rear left 145/1,2/HL 180/120/1,7/HL Rear right 145/1,2/HL Forward right...
  • Page 20 172731_en.indd 20 172731_en.indd 20 9.1.2007 14:52:06 9.1.2007 14:52:06...
  • Page 21 172731_en.indd 21 172731_en.indd 21 9.1.2007 14:52:06 9.1.2007 14:52:06...
  • Page 22 172731_en.indd 22 172731_en.indd 22 9.1.2007 14:52:06 9.1.2007 14:52:06...
  • Page 23: Warranty Registration

    Kleenmaid appliance, we guarantee that any fault caused by faulty material or workmanship becoming apparent, will be rectified free of charge for parts and labour, provided that all service is performed during normal working hours by Kleenmaid or their designated Agents.
