Summary of Contents for Kleenmaid CH17
- Page 1 C O O K TO P c o l l e c t i o n Instr uctions for Use and Warranty Details Ceramic Cooktops CH17 - Ceramic Touch Control 600 mm CH18 - Ceramic Touch Control 780 mm...
- Page 2 Kleenmaid appliance. This appliance has been designed and manufactured to give you years of reliable performance. For best results, carefully read the instructions on how to install your new appliance. Correct installation will avoid delays and unnecessary service calls.
-
Page 3: Table Of Contents
CONTENTS General description ............Description of sensors ............Description of timer ............... Operating 5,6,7,8 ............... Safety ................... Considerations ................ Using pans ................Cleaning ................. Installation 12,13,14 ..............Wiring Diagram 15,16 .............. Warranty and Service ............WARNING • Repair of any fault in your hob must be carried out only by an Authorized Repair Agent, otherwise the guarantee is not valid. -
Page 4: General Description
GENERAL DESCRIPTION DOUBLE HOTPLATE MODEL CH17 Control sensors DOUBLE HOTPLATE MODEL Control CH18 sensors... -
Page 5: Description Of Sensors
DESCRIPTION OF SENSORS MODELS: CH17 and CH18 Double hotplate control point Double hotplate sensors Hotplate pilot light Selected power display Residual heat display Power sensors from 0 to 9 from 9 to 0 Blocking control point Blocking sensor ON/OFF... -
Page 6: Description Of Timer
DESCRIPTION OF TIMER MODEL-CH-18 The double hotplate is equipped with a minute timer (1 to 99) that automatically switches off the heat and sounds an alarm at the end of the selected time. The double hotplate can operate with or without programming. Setting the timer Touch the sensor +/- sensor for the clock to set... -
Page 7: Operating
OPERATING Sensors The vitroceramic cooking surface is fitted with sensors that are touch- sensitive and also react to the presence of a reflective object. The hotplates are operated by touching the corresponding sensors with your fingers. Take care to touch only one sensor at a time, otherwise they will not react to the touch. - Page 8 OPERATING - / + Selecting power. Each hotplate has - / +. power sensors. Touching these allows the power to be adjusted in the range To alter the power while the hotplate is on, touch - / + sensors to obtain the required power level.
- Page 9 OPERATING Hotplate blocking function. The blocking of the hotplates prevent accidental changes while they are operating. The initial selections are maintained and the indicators remain active. The hotplates should be blocked to prevent children from operating them or to prevent the effects of accidental contact with containers or tools. Press the blocking sensor until its pilot light comes on.
- Page 10 OPERATING Automatic programming (quick heating) Each control area includes an automatic programming function. This programming allows the corresponding maximum temperature to be reached quickly and maintained automatically. Selection. Touch the sensor + once to turn on its decimal point, if it is in position the display will show Pre-selection is active for 10 seconds to allow the required power level to be selected.
-
Page 11: Safety
Important. If the vitroceramic surface breaks or you notice cracks in it, disconnect the equipment. Call Kleenmaid Customer Call Centre for service assistance. Automatic. If a hotplate is left on accidentally, it will automatically be switched off after a period of time has elapsed, depending on the power level that has been 1 - 10 hours, level 9 - 1 hour). -
Page 12: Using Pans
USING PANS STAINLESS STEEL Most stainless steel, enamel, iron, ENAMEL ceramic and copper pans can be used CERAMIC on vitroceramic hobs. COPPER ALUMÍNIUM ALUMÍNIUM Aluminium pans are not recommended as they may stain the vitreous surface, unless they have stainless-steel covered bottoms. -
Page 13: Cleaning
CLEANING Clean the vitroceramic surface frequently, when it is cool. Never use abrasive products or pads. Clean SOAP + WATER with a damp cloth and soapy water. SCOURER Once a week, clean thoroughly with specific products that preserve and protect vitroceramic hobs. Scrape off hard stuck dirt with the scraper (Included in accessory bag). -
Page 14: Installation
INSTALLATION The vitroceramic hotplate is supplied with a power cable prepared for 220 to 240V AC. The cooktop must be connected to the main supply with the cable provided. Total power Hotplate: 60 cms., 6.3kW, Hotplate: 75 cms., 7.4 kW Three phase PLATE Voltage... -
Page 15: Installation 12
INSTALLATION Cut out a piece of the worktop following the dimensions provided below. Minimum distance between hole and side wall 100 mm. Minimum distance between hole and rear wall 50 mm. MODEL: CH18 Place the hob face down on a table. -
Page 16: Installation 12
Kleenmaid will not accept responsability for installations carried out other than as directed here. The cooktop is equipped with a power input cable for high temperatures and must be installed with this cable. -
Page 17: Wiring Diagram
WIRING DIAGRAM... - Page 18 WIRING DIAGRAM...
-
Page 19: Warranty And Service
Kleenmaid appliance, we guarantee that any fault caused by faulty material or workmanship becoming apparent will be rectified free of charge for parts and labour, provided that all service is performed during normal working hours by Kleenmaid or their designated Agents. - Page 20 Other products in Kleenmaid’s range of world’s best appliances: • Washers • Dryers • Vacuum Cleaners • Dishwashers • Cooktops • Cookware • Rangehoods • Ovens • Refrigerators & Freezers • Sinks & Taps • Waste Disposals For sales information on the full range of quality...
