Summary of Contents for Kleenmaid CH311XFF
- Page 1 C o o k i n g C o o k i n g c o l l e c t i o n c o l l e c t i o n Instructions for Use Warranty Details Gas Cooktops...
- Page 2 ongratulations on the purchase of your new appliance. This appliance has been designed and manufactured to give you years of reliable performance. For best results, carefully read the instructions on how to install your new appliance. Correct installation will avoid delays and unnecessary service calls. Once installation is complete, read this booklet carefully and get to know the controls and the features of your new appliance.
-
Page 3: Table Of Contents
CONTENTS General Information…………………………………………………………………….. Page 3 Warning and Safety Instructions………………………………………………………. Page 4 Instructions for Use……………………………………………………………………... Page 5 – 7 Installation Instructions……………………………………………………………….… Page 8 – 13 Technical Data……………………………………………………………….………….. Page 14 – 15 Conditions of Warranty……………………………………………………………….… Page 16... -
Page 4: General Information
Safety Standards – EN 60 335-1, EN 60 335 – 2 – 6, EN 30-1-1. AS/NZS 3350-1, 3350-2-6 As Kleenmaid have a policy of continued product improvement, the right is reserved to adjust and make any modifications deemed necessary without notification. -
Page 5: Warning And Safety Instructions
§ Kleenmaid advise that the appliance is not intended for use by young children or infirm persons without supervision. If it is necessary for younger family members to be in the kitchen, ensure that they are kept under close supervision at all times. -
Page 6: Instructions For Use
The following models are covered by these instructions: CH311XFF 2 burner, stainless steel hob, enamel trivets with flame failure & auto ignition. CH311WOKFF Single wok burner, stainless steel hob, enamel trivets with flame failure & auto ignition. -
Page 7: Helpful Hints
Burners extinguished by cupboard doors. § Gas valves, which are difficult to turn. In case the appliance fails to operate correctly, contact your nearest Authorised Kleenmaid Service Agent by phoning 1300 652 100. WARNING: Servicing should be carried out only by authorised personnel. -
Page 8: Cleaning The Appliance
INSTRUCTIONS FOR USE CLEANING THE APPLIANCE Always allow the appliance to cool down before cleaning to avoid a burn injury. Do not use caustic or abrasive agents, coarse wire wool or hard tools as these can damage the surface finishes. Normally, wiping with a soft cloth dampened with hot detergent solution is sufficient but for stubborn marks the following is recommended: Vitreous Enamel parts –... -
Page 9: Installation Instructions
PRE-COMMISSIONING THE APPLIANCE When unpacked, check that the following parts are included with the appliance: - § Kleenmaid Instruction and Installation Book § Pan Supports § Burner Assemblies §... -
Page 10: Installation Notes
5. Insert the appliance into the aperture and fix in position via the clamps & screws, tightening the screws evenly (see Fig 1 below). 6. Models CH311WOKFFand CH311XFF must be installed with the spacers that are attached to the underside of the cooktop. If installed in a bench with an open cupboard, a dividing shelf must be installed no nearer than 20mm to the underside of the unit which is identified by the spacers. -
Page 11: Gas Connection
For the location of the Gas Connection please refer to the following table: MODEL Inlet Position Inlet (mm) Inlet (mm) from side from rear CH311XFF RHS Rear CH311WOKFF RHS Rear CH607X CH607W RHS Rear CH609X CH609W RHS Rear... - Page 12 INSTALLATION INSTRUCTIONS GAS FLOW ADJUSTMENT (see Fig 4 Page 12) In order to adjust the minimum gas flow proceed as follows: § Ignite the burner and turn down to the minimum setting. § Remove the control knob from the gas tap. §...
- Page 13 INSTALLATION INSTRUCTIONS ADAPTATION TO VARIOUS TYPES OF GAS Should the appliance be pre-set for a different type of gas than that available, proceed as follows: • Replace the injectors (Fig 3) with the corresponding type of gas to be used (See table Page 15). •...
-
Page 14: Electrical Connection
INSTALLATION INSTRUCTIONS ELECTRICAL CONNECTION Before connecting the appliance, make sure the supply voltage marked on the rating Plate corresponds with the mains supply voltage. WARNING – THIS APPLIANCE MUST BE EARTHED Ensure the appliance is plugged into a 10amp GPO IMPORTANT The wires in the main supply lead are coloured in accordance with the following code:- Green and Yellow -... -
Page 15: Technical Data
WARNING: SERVICING SHOULD BE CARRIED OUT ONLY BY AUTHORISED PERSONNEL During the warranty period, in case of need all service intervention should be referred back to the Kleenmaid Service Department. Please note that intervention or repair by any unauthorised personnel will invalidate such warranty. - Page 16 TECHNICAL DATA NATURAL GAS BURNER TYPES AND POWER INPUTS: Mj/h Semi MODEL Rapid Auxiliary Total Mj/h Rapid CH311XFF 10.5 CH311WOKFF 14.5 14.5 CH607X CH607W 11.2 28.3 CH609X CH609W 14.5 31.6 CH611XFF CH611WFF 14.5 11.2 36.2 CH711XFF 14.5 11.2 42.8 CH911XFF 14.5...
-
Page 17: Conditions Of Warranty
Kleenmaid appliance, we guarantee that any fault caused by faulty material or workmanship becoming apparent, will be rectified free of charge for parts and labour, provided that all service is performed during normal working hours by Kleenmaid or their designated Agents. - Page 18 Other products available in the Kleenmaid Range of appliances Washers Dryers Dishwashers Ovens Cooktops Outdoor Cooking Centres Built In Coffee Machines Rangehoods Freestanding Ranges Sinks Waste Disposals Taps Cookware Refrigerators Freezers Wine Cellars Vacuum Cleaners For sales information on the full range of quality appliances...
