Summary of Contents for Kleenmaid cooking CCTB6010

  • Page 1 cooking collection Instructions for use and warranty details Ceramic CCTB6010...
  • Page 2 Once installation is complete, please read this instruction manual carefully and get to know the controls and the features of your new Kleenmaid appliance. These simple instructions will enable you to achieve excellent results from the very first time you use it.

  • Page 3: Table Of Contents

    Content 1. Foreword ..................3 1.1 Safety Warnings ................. 3 1.2 Installation ................3 1.2.1 Electrical Shock Hazard ..........3 1.2.2 Cut Hazard ..............3 1.2.3 Important safety instructions .......... 3 1.3 Operation and maintenance ............4 1.3.1 Electrical Shock Hazard ..........4 1.3.2 Health Hazard ..............

  • Page 4: Foreword

    1. Foreword 1.1 Safety Warnings Your safety is important to us. Please read this information before using your cooktop. 1.2 Installation 1.2.1 Electrical Shock Hazard  Disconnect the appliance from the mains electricity supply before carrying out any work or maintenance on it. ...

  • Page 5: Operation And Maintenance

     Failure to install the appliance correctly could invalidate any warranty or liability claims.  This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

  • Page 6: Health Hazard

     Switch the cooktop off at the wall before cleaning or maintenance.  Failure to follow this advice may result in electrical shock or death. 1.3.2 Health Hazard  This appliance complies with electromagnetic safety standards however, persons with cardiac pacemakers or other electrical implants (such as insulin pumps) must consult with their doctor or implant manufacturer before using this appliance to make sure that their implants will...
  • Page 7  Never use your appliance for warming or heating the room.  After use, always turn off the cooking zones and the cooktop as described in this manual.  Do not allow children to play with the appliance or sit, stand, or climb on it.

  • Page 8: Product Introduction

    2. Product Introduction 2.1 Top View 1. Max. 1200 W zone 2. Max. 1800 W zone 3. Max. 1200 W zone 4. Max. 1800W zone 5. Glass plate 6. Control panel 2.2 Control Panel 1. Hot cooktop warning indicators 2. Power regulating controls 2.3 Product Information This ceramic cooktop directly employs resistance wire heating, and output power is adjusted with the mechanical power regulating controls.

  • Page 9: Before Using Your New Ceramic Cooktop

    2.4 Before using your New Ceramic Cooktop  Read this guide, taking special note of the ‘Safety Warnings’ section.  Remove any protective film that may still be on your ceramic cooktop. 2.5 Technical Specification Cooktop Model CCTB6010 Cooking Zones 4 Zones Supply Voltage 220-240V~ 50Hz or 60Hz...

  • Page 10: How To Use

    3.2 How to use 3.2.1 Start cooking Place a suitable pan on the cooking zone that you wish to use. • Make sure the bottom of the pan and the surface of the cooking zone are clean and dry. Adjust the power regulating control to the desired level. 3.2.2 Finish cooking Turn the cooking zone off by turning the power regulating control to “OFF”.

  • Page 11: Simmering, Cooking Rice

    4.1.1 Simmering, cooking rice  Simmering occurs below boiling point, at around 85˚C, when bubbles are just rising occasionally to the surface of the cooking liquid. It is the key to delicious soups and tender stews because the flavours develop without overcooking the food. You should also cook egg-based and flour thickened sauces below boiling point.

  • Page 12: Care And Cleaning

    6. Care and Cleaning What? How? Important! 1. Switch off the power to the Everyday soiling on • When the power to the cooktop is glass (fingerprints, cooktop. switched off, there will be no ‘hot 2. Apply a cooktop cleaner while marks, stains left by surface’...

  • Page 13: Installation

    8. Installation 8.1 Preparation of Benchtop Cut out the work surface according to the sizes shown in the drawing. For the purpose of installation and use, a minimum of 5 cm space shall be preserved around the hole. Be sure the thickness of the work surface is at least 30mm. Please select heat-resistant and insulated work surface material (Wood and similar fibrous or hygroscopic material shall not be used as work surface material unless impregnated) to avoid the electrical shock and larger deformation caused by the heat radiation from the hotplate.

  • Page 14: Before Locating The Fixing Brackets

    WARNING: Ensuring Adequate Ventilation Make sure the ceramic cooktop is well ventilated and that the air inlet and outlet are not blocked. In order to avoid accidental contact with the overheating bottom of the cooktop whilst working, it is necessary to put a wooden insert, fixed by screws, at a minimum distance of 50mm from the bottom of the hob.

  • Page 15: Cautions

    Under no circumstances should the brackets touch the inner surfaces of the worktop after installation (see picture) 8.3 Cautions 1. The ceramic cooktop must be installed by qualified personnel or technicians. Should you require assistance to find an installer the contact details for technicians in various areas are available on our website (see back cover of this manual).
  • Page 16 1. If the cable is damaged or needs replacing, this should be done by a qualified technician using the proper tools, so as to avoid any accidents. 2. If the appliance is being connected directly to the mains supply, an omnipolar circuit breaker must be installed with a minimum gap of 3mm between the contacts.
  • Page 17 The benefits given to you under this Kleenmaid Warranty are in addition to other rights and remedies to which you may be entitled under the Australian Consumer Law in relation to the Product to which this Kleenmaid Warranty relates. Subject to the conditions below, the Product is warranted by Kleenmaid and/or its agents to be free from defects in materials and workmanship for the Warranty Period for normal Domestic Use.
  • Page 18 13. Kleenmaid accepts no liability for items that are lost, damaged, or stolen as a result of freight, transport or storage. If you are required to transport the Product to an authorised service centre, you must ensure that it is securely packed and insured.
  • Page 19 This page is intentionally left blank.
  • Page 20 Other products available in the Kleenmaid range of appliances Washing machines Clothes dryers Dishwashers Ovens Cooktops Steam ovens Microwave ovens Built in espresso coffee machines Rangehoods Freestanding ovens Refrigerators & Freezers Beverage Serving Cabinets Water Dispensers Vacuum Cleaners Compass Capital Services Pty Limited...
