- Page 1 C O O K TO P c o l l e c t i o n Instr uctions for Use and Warranty Details Solid Hotplate Cooktops CH40S - 600 mm Stainless Steel CH41W - 600 mm White CH42B - 600 mm Black...
- Page 2 Kleenmaid appliance. This appliance has been designed and manufactured to give you years of reliable performance. For best results, carefully read the instructions on how to install your new appliance. Correct installation will avoid delays and unnecessary service calls.
-
Page 3: Table Of Contents
CONTENTS General description ......2 Use of controls ......2 Use of pans . -
Page 4: General Description
GENERAL DESCRIPTION 4 ELECTRIC HOTPLATE USE O TYPE: EI-4E 1,5kW 1,5kW USE OF CONTROLS Make sure that you operate the right control for the burner you wish to use ELECTRICAL PLATES Electrical plates have 6 positions giving different heat outputs. Table 1, gives a guide to these outputs. -
Page 5: Use Of Pans
TABLE 1 MINIMUM MÁXIMUM MEDIUM HIGH Boil and roast Boil and roast red white meats, meats, minced meat, Keep warm fish or omelettes. puddings. Prepare Fry potatoes, fish, Boil potatoes, delicate sauces pasta. pulses, soups and cremes Boil relatively large Prepare quantities of water sauces... -
Page 6: Cleaning
CLEANING IMPORTANT: First of all, switch off the equipment. If your top is stainless steel, there are adequate products available in shops that you may use. Once it is clean, rinse the top with water and a soft cloth. If the top is enamelled, use soapy water to clean it. -
Page 7: Installation
INSTALLATION Before the installation, please check all measures of the equipment and fit-in housing. Cut out a piece of the worktop following the instructions. Equipment type “X” for fire protection grade. NOTE: The worktop must be provided with a shelf “A” so that the top cannot be reached from inside, due to the temperatures it reaches. - Page 8 INSTALLATION Then, place the hob in the cavity in the woktop. Press down tightly so that sealing joint is perfectly closed. Fix the 4 clamps underneath the hob to the corresponding 4 corners of the cavity. (Clamps and nuts are supplied in the accessory bag).
-
Page 9: Connections Sheamtic
CONNECTIONS SCHEAMTIC The hot plate is supplied with a power cable (N2GMH2G types) prepared for 220...240V AC. If the type of connections to which the hotplate is to be installed is other than 220 to 240 V Ac rmove the cable and make the connection according to the adjacent drawings. -
Page 10: Wiring Diagram
WIRING DIAGRAM... -
Page 11: Warranty And Service
Kleenmaid appliance, we guarantee that any fault caused by faulty material or workmanship becoming apparent will be rectified free of charge for parts and labour, provided that all service is performed during normal working hours by Kleenmaid or their designated Agents. - Page 12 Other products in Kleenmaid’s range of world’s best appliances: • Washers • Dryers • Vacuum Cleaners • Dishwashers • Cooktops • Cookware • Rangehoods • Ovens • Refrigerators & Freezers • Sinks & Taps • Waste Disposals For sales information on the full range of quality...
