GL530MG User Manual
EGPRS/LTE Cat-M1/LTE Cat-NB2/GNSS Tracker
TRACGL530MGUM001
V1.02

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GL530MG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Queclink GL530MG

  • Page 1 GL530MG User Manual EGPRS/LTE Cat-M1/LTE Cat-NB2/GNSS Tracker TRACGL530MGUM001 V1.02...
  • Page 2 TRACGL530MGUM001 General Notes Queclink offers this information as a service to its customers, to support application and engineering efforts that use the products designed by Queclink. The information provided is based upon requirements specifically provided to Queclink by the customers. Queclink has not undertaken any independent search for additional relevant information, including any information that may be in the customer’s possession.
  • Page 3: Table Of Contents

    GL530MG User Manual Contents History ..........................- 3 - 1. Introduction ......................... - 4 - 1.1. Specifications ....................- 4 - 1.2. Reference ......................- 4 - 1.3. Terms and Abbreviations .................. - 4 - 2. Product Overview ....................... - 5 - 2.1.
  • Page 4: History

    GL530MG User Manual History Revision Date Author Description of Change Super Zhao Initial. 1.00 June 23, 2021 Super Zhao Added the SIM card note. 1.01 March 15, 2023 Added the description of the method to Tammy Tian 1.02 April 11, 2023 wake up the device in Chapter 4.3.
  • Page 5: Introduction

    GL530MG User Manual 1. Introduction The GL530MG is an IP67-compliant GNSS tracker that features up to 7 years of standby time powered by the internal battery. The device supports multiple bands of LTE CAT-M1 (eMTC) network that are used in both North America and Europe, which is ideal for asset monitoring and lot management that require tamper detection and temperature monitoring.
  • Page 6: Product Overview

    LEDs Light Alarm Sensor Figure 1. GL530MG Appearance 2.2. Key Description Table 4. GL530MG Key Description To power on: Long press for more than 3 seconds To check the device status: Press the function button once Functions To power off (configuration is required): Long press for more than 3s...
  • Page 7: Led Description

    There are two LEDs on the device, which can work separately or together to indicate the status of the device. Please refer to the following table when two LEDs work separately: Table 5. GL530MG LED Description (work separately) Device Status...
  • Page 8: Parts List

    GL530MG User Manual Table 6. GL530MG LED Description (work in combination) Both the LEDs will be on to indicate the device is During power-on powered on. The Status LED will be on to indicate the device still When checking the device status works.
  • Page 9: Battery Specifications

    GL530MG User Manual GL530MG UART Data It is used for configuration. Cable (Optional) GL530MG USB Data It is used for firmware upgrade. Cable (Optional) 2.5. Battery Specifications Capacity 1400mAh Type 3 CR123A lithium batteries Standby Time 1 report per day (GNSS on): Up to 5 years...
  • Page 10: Interface Definition

    GL530MG User Manual 3. Interface Definition The GL530MG has an internal 5-pin connector. It can be used to configure the device or update the firmware (a different cable is required). The definition of the pins is in the following table.
  • Page 11: Getting Started

    4.2. Turning on/off the Device Battery Switch Figure 5. GL530MG Battery Switch and Key To turn on the device: Toggle the battery switch on the PCB from the OFF to the ON position. Or long press the power button for more than 3 seconds if the battery switch is already in the ON position.
  • Page 12: Waking Up The Device

    GL530MG User Manual To turn off the device (configuration is required): Long press the power button for more than 3 seconds after power on. To completely cut off the power supply: The battery switch on the PCB must be in the OFF position.
  • Page 13 GL530MG User Manual The battery switch is in the OFF position. Figure 7. Power off the device Step 2 Open the flip SIM card holder. Make sure the small notch in the corner of the SIM card matches the one in the SIM card tray so that it fits properly. Install a SIM card on the holder with the words or logo facing up.
  • Page 14 GL530MG User Manual Step 3 Close the flip SIM card holder. Toggle the battery switch to the ON position to power on the device. The battery switch is in the ON position. The SIM card holder is secured. Figure 9. Power on the device Note: The SIM card holder must be secured at any time when the device is being turned ON.
  • Page 15: Installation Precautions

    GL530MG User Manual 5. Installation Precautions  Firmly fix the device to a reliable surface to prevent falling off.  Let the side with the GNSS antenna face up to have better signal reception.  Don’t install the device under a metal surface or in enclosed environments, which makes it difficult to get GNSS or network signals.
  • Page 16 GL530MG User Manual TRACGL530MGUM001 - 15 -...
  • Page 17: Troubleshooting And Safety Info

    GL530MG User Manual 6. Troubleshooting and Safety Info 6.1. Troubleshooting Table 9. GL530MG Troubleshooting List Issue Possible Cause How to Fix 1. The cellular signal strength The Status LED flashes Please place the device in an is weak; fast when the device is area with good network 2.
