1664 Barcode Scanner

4.11 GS1-128 (EAN-128)

Note: GS1-128 barcodes can be decoded only when this setting is enabled.

4.11.1 TRANSMIT CODE ID

Decide whether to include the Code ID ("

4.11.2 FIELD SEPARATOR (GS CHARACTER)

Decide whether to apply a field separator (to convert the
readable character).
1) Read the barcode above to enable field separator.
2) Read the "Hexadecimal
3) Read the "Validate" barcode to complete this setting.
Note: GS1-128 barcodes start with the
from other uses of Code 128.
GS1-128 barcodes.
132
User Guide
Value" barcode on page 252 for the desired character string.
FNC1
*Enable
Disable
") in the data being transmitted.
]C1
Transmit GS1-128
Code ID
*Do Not Transmit
FNC1
Enable Field
Separator...
control character to distinguish themselves
FNC1
is also used to separate data fields in the
control character to human
Enter Setup
