Using Bluetooth ® Dongle - CipherLab 1664 User Manual

1664 Barcode Scanner
Note: Because 1664 supports the downloading of firmware via Direct USB Virtual COM
interface, the output interface will be set to the previously used one upon
completion of firmware upgrade.
USING BLUETOOTH
®
1) Refer to 3.2.3 Connect to Dongle
request from your computer.
2) Read the following barcodes in sequence to configure the scanner to use Bluetooth
SPP as download interface.
3) Read the following barcodes in sequence for the scanner to enter the download mode.
The scanner will respond with beeps to indicate it is ready for downloading.
4) Run the download utility "ProgLoad.exe" on your computer.
Kernel Program
K1664_V*.shx
236
User Guide
DONGLE
Enter Setup
Enter Setup
for the target scanner to accept the connection
Activate Bluetooth
Update
Download
User Program
STD1664_V*.shx
®
SPP
Enter Setup
®
