Trigger action
Now that you have the event trigger duration and interval defined,
choose what action to be taken during an event trigger:
• You can choose to have the recorder send out the first few frames
of the video recorder upon an event is triggered
• You can also choose to have the recorder send out a warning message in e-
mail or in txt file format and upload it to a destined FTP server
3.3.2 I/O Settings
This function allows users to manage camera's digital input and output ports right
from the recorder. You can setup the recorder to receive triggers from a particular
camera's input port and trigger a device, such as an alarm that is connected to
the recorder or camera's output port. Cameras that do not have built-in digital
input/output port can also be configured to pair with the recorder's DI/DO ports.
1. For cameras that come with physical digital input ports, their ports will be listed
in the far left drop-down menu.
2. Pick the desired channel for I/O mapping, and then select the camera's input
port from the drop-down menu.
3. Select the trigger condition from the "Condition" drop-down menu.
4. Select the recorder's input port if you would also like to use the recorder's
input port for event trigger. And then select the trigger condition as well.
5. Next, select the recorder's output port and the trigger action
6. Finally, define the trigger duration.
