Network Video Recorder User Manual 1.0.0.22 Product name: Network Video Recorder Release Date: 2015/05 Manual Revision: V1.0 Web site: www.brickcom.com support@brickcom.com Email: info@brickcom.com Information in this document is subject to change without notice. © Copyright 2015. All rights reserved. -
Page 2: Table Of Contents
Table of Contents Chapter 1. Introduction ................2 Hardware Description ................. 3 1.1.1 NR-1100 Series ................. 3 1.1.2 NR-2100 Series ................. 4 1.1.3 NR-4200 Series ................. 5 1.1.4 NR-8200-RM Series ................6 LED Indicators Status..................7 1.2.1 NR-1100 Series ................. 7 1.2.2... -
Page 3: Chapter 1. Introduction
Chapter 1. Introduction Before You Use This Product When you first open the product’s package, verify that all the accessories listed on the “Package Contents” of “Quick Installation Guide” are included. Before installing the NVR, please read the instructions in the “Quick Installation Guide” to avoid misuse and then follow the instructions in the “Hard Disk Installation”... -
Page 4: Hardware Description
1.1 Hardware Description 1.1.1 NR-1100 Series Figure 1-1. Front & Rear View of NR-1100 Series Power button LED indicators: HDD USB 2.0 x1 (Support auto video backup) USB 2.0 x1 Power connector USB 3.0 x 2 DVI-I eSATA x 1 HDMI x 1 10. -
Page 5: Nr-2100 Series
1.1.2 NR-2100 Series Figure 1-4. Front & Rear View of NR-2100 Series Power button LED indicators: HDD USB 2.0 x1 (Support auto video backup) USB 2.0 x1 Power connector USB 3.0 x 2 DVI-I eSATA x 1 HDMI x 1 10. -
Page 6: Nr-4200 Series
1.1.3 NR-4200 Series Figure 1-5. Front & Rear View of NR-4200 Series LED indicators: LAN1, LAN2, eSATA, HDD1, HDD2, HDD3, HDD4 Power button USB BACKUP button - Auto video backup USB 2.0 x 1(Support auto video backup) USB 2.0 x 1 HDD1 HDD2 HDD3... -
Page 7: Nr-8200-Rm Series
1.1.4 NR-8200-RM Series Figure 1-8. Front & Rear View of NR-8200-RMSeries 1. LED indicators: LAN1, LAN2, eSATA, HDD1, HDD2, HDD3, HDD4, HDD5, HDD6, HDD7, HDD8 2. Power button 3. USB BACKUP button - Auto video backup 4. USB 3.0 x 1 (Support auto video backup) 5. -
Page 8: Led Indicators Status
1.2 LED Indicators Status 1.2.1 NR-1100 Series Figure 2-3. NR-1100 Series Front Panel Note: **To turn off your NVR, long pressing power button at least 2 seconds. **To turn on your NVR, long pressing power button at least 3 seconds. -
Page 9: Nr-2100 Series
1.2.2 NR-2100 Series Figure 2-4. NR-2100 Series Front Panel Note: **To turn off your NVR, long pressing power button at least 2 seconds. **To turn on your NVR, long pressing power button at least 3 seconds. Note: To reset to default, please follow below methods: Press the power button twice with the interval of one second. -
Page 10: Nr-4200 Series
1.2.3 NR-4200 Series Figure 2-5. NR-4200 Series Front Panel & RJ-45 Port LED on Front Panel LED Color & Status Indicate LAN Link is not established Orange LAN Link is established Orange blinking LAN is being accessed No data transmission eSATA Orange blinking The eSATA device is being accessed... - Page 11 LED on RJ-45 Connection at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow LAN Link is established LAN2 (Right LED) Yellow Blinking LAN activity is occurring 10Mbps connection or no connection LAN1 Speed Green 100Mbps connection LAN2 (Left LED)
-
Page 12: Nr-8200-Rm Series
1.2.4 NR-8200-RM Series Figure 2-8. Front View of NR-8200-RM Series & RJ-45 Port LED on Front Panel LED Color & Status Indicate LAN Link is not established Orange LAN Link is established Orange blinking LAN is being accessed No data transmission eSATA Orange blinking The eSATA device is being accessed... - Page 13 LED on RJ-45 Connection at Rear Panel LED Position LED/State Indicate LAN Link is not established LAN1 Link/Activity Yellow LAN Link is established LAN2 (Right LED) Yellow Blinking LAN activity is occurring 10Mbps connection or no connection LAN1 Speed Green 100Mbps connection LAN2 (Left LED)
-
Page 14: Dual Display Solution: Hdmi/Vga/Dvi-I Connection
HDMI and VGA at the same time for video output. NR-1100 Series, NR-2100 Series provide HDMI and DVI-I port for local display. Users can connect both of HDMI and DVI-I at the same time for video output. -
Page 15: Chapter 2. Nvr Installation
Chapter 2. NVR Installation 2.1 Remote Web Browser PC System Requirements The following information is the minimum required specification for remote Windows PC, which users can open a remote browser from the PC to access the Linux NVR server on the network. Operating System Microsoft®... -
Page 16: Connect To Nvr
2.2 Connect to NVR To begin, please insert the product CD-ROM in a PC to access the Quick Guide, User Manual and install the utilities. As user runs the product CD, the following menu is displayed. 2.2.1 Quick Guide Click “Quick Guide” to enter the folder and double click the file to open. Please read Quick Guide to quickly understand the process of NVR installation. - Page 17 Once a folder is selected, please click “OK” to continue installation. The window shows that the InstallShield Wizard is installing NVR Search. Please wait until the Wizard completes the installation. The installation is complete. Please click “Launch application when done installing” to execute NVR Search.
- Page 18 Address and Model name of connected NVR. Users can click “Search” to search NVR. Introduction of NVR Search NVR Search provides three kinds of toolbars for users: File You can click “Exit” to leave NVR Search and close the window.
- Page 19 2. Setting Configure UPnP and Network by clicking “Setting” in the top left or in the middle right. Note: Users will be prompted to enter the login information of NVR before being allowed to change the setting. When accessing the NVR setting, users will be prompted to enter username and password.
- Page 20 1) UPnP Universal Plug and Play (UPnP) simplifies the process of adding a NVR to a local area network. Once connected to a LAN, NVR will automatically appear on the internet. You can rename UPnP Name on the NVR. Click “OK” to finish the setting.
- Page 21 3. Option Option provides several languages Once you click “Connect” or double click the selected NVR list, IE browser will pop up automatically for the web-based interface.
-
Page 22: Activate Live View Service
Activate Live View Service 2.2.3 Log in to the system by entering its IP address in IE browser. Note: There are 2 methods to set network: Obtain an IP address automatically (NVR Default) Obtain an available dynamic IP address assigned by a DHCP server. If this option is selected, NVR will automatically obtain an available dynamic IP address from the DHCP server once it connects to the network. -
Page 24: Quick Configuration
Quick configuration 2.2.4 After you install the ActiveX control, the system will direct you to set Quick Configuration in 5 steps. Follow the instructions of the Overview of wizard to complete the system setup. Once the five steps of Quick Configuration are complete, you can click “Start Liveview”...
