- Page 1 Ethernet over Coax EoC-1000M & EoC-1000S User’s Manual Quality Service Group...
- Page 2 Ethernet over Coax Product name: (EoC-1000M & EoC-1000S) Release Date: 2013/07 Manual Revision: V1.0 Web site: www.brickcom.com Email: technical@brickcom.com info@brickcom.com © 2013 Brickcom Corporation. All Rights Reserved...
- Page 3 EoC-1000-series Overview EoC-1000M 24V 2.7A Data + Power Socket Power(OUT) Data LED Power LED Ethernet LED Ethernet port EoC-1000S Data + Ethernet port Power(IN) Data LED 12V 1A Ethernet LED (Power out) Power LED...
- Page 4 4. Connect power cord into 12VDC out port and IP CAM power port. 5. Finally, plug in the 24V 2.7A power supply to EoC-1000M’s power port. ※1. Please note to plug in the power supply is must be the Final step.
