Page 1: Quick Installation Guide
Network Video Recorder Quick Installation Guide NR-1104 Information in this document is subject to change without notice. © Copyright 2013, BRICKCOM Corporation. All rights reserved. -
Page 2: Pre-Installation Notice
Thank you for choosing BRICKCOM Network Video Recorder. The following quick guide will lead you to complete the installation and configuration of the NVR. Please read the following description carefully. Pre-installation Notice Please make sure the following items are prepared for installing BRICKCOM NVR. Network connection ... - Page 3 For channels over 16: IDDR3 8G or above Graphics Adapter AGP or PCI-Express, minimum 1024×768, 16 bit colors, 1G memory or above Note: It is highly recommended to use a graphics adaptor which provides higher than resolutions 1024 x 768 in order to experience the full benefits of the software.
-
Page 4: Package Contents
Package Contents NVR Network Video Recorder Power Cord Power adaptor Screw Bag 2.5" HDD Bracket Stand Ethernet Cable Assembly drawing Product CD... -
Page 5: Hardware Description
Hardware Description Front View Rear View Power button LED indicator: HDD USB 2.0 x2 Power connector USB 3.0 x 2 DVI-I eSATA x 1 HDMI x 1 Gigabit LAN 10. USB 2.0 x 2 11. Audio mic input 12. Audio output... -
Page 6: Hard Disk Installation
Hard Disk Installation Please follow the steps as illustrated below to install the hardware:... - Page 7 Connection to BRICKCOM NVR Please insert the product CD-ROM on a PC to install NVR Search and NVR Decoder. Finally, you can start Quick Configuration on a web page. Install NVR Search for finding NVR in the network.
- Page 8 Connect to NVR 1. Connect to NVR After setting the NVR Search and NVR Decoder, the user can connect to the monitoring page by the following two options: NVR Search Once you click “Connect” or double click the selected NVR list, the IE browser will pop up automatically.
- Page 9 different IP address of NVR if there is more than one NVR in the same LAN. 2. Enter a user name and password Log in the NVR with the default administer account (user name: admin, password: admin). 3. Install the ActiveX control in order to successfully view the interface of NVR from IE browser...
-
Page 10: Quick Configuration
Quick configuration After you install the ActiveX control, the system will direct you to set Quick Configuration in 5 steps. Follow the instructions of the Overview of wizard to complete the system setup. Once the five steps of Quick Configuration are complete, you can click “Start Liveview”...
