- Page 1 Oxygen ORDERCODE D2150...
- Page 2 Congratulations! You have bought a great, innovative product from DAP Audio. DAP Audio Oxygen brings excitement to any venue. Whether you want simple plug-&-play action or a sophisticated show, this product provides the effect you need. You can rely on DAP Audio, for more excellent audio products.
-
Page 3: Table Of Contents
DAP Audio DAP Audio Oxygen Product Guide ™ Warning..…...................………………………………………….. Safety-instructions………………………………………………………………………………………….…. Operating Determinations……………………………………………………………………………………. Description..…................……….………………………………… Features………………………………………………………………………………….………………….…. Overview ..…………………………………………………………………………………….………..……. Frontside.………………………………………………………………………….………..………………... Backside.………………………………………………………………………….………..……………..…. Installation................…...……………………………………..…. Set Up and Operation..............……..…………………………….….. Set Up ………………..........…………………………………....……..Connection Cables......…........………..………….…….………….…. Maintenance………......…........………..………….…….………….…. Troubleshooting………......…........………..………….…….………….….. Product Specifications..............……………….…….………………….. -
Page 4: Warning
WARNING CAUTION! Keep this system away from rain and moisture! FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY BEFORE YOUR INITIAL START-UP! SAFETY INSTRUCTIONS Every person involved with the installation, operation and maintenance of this system has to: be qualified follow the instructions of this manual CAUTION! Be careful with your operations. -
Page 5: Operating Determinations
Make sure you don’t use the wrong kind of cables or defective cables. • Make sure that the signals into the mixer are balanced, otherwise hum could be created. • Make sure you use DI boxes to balance unbalanced signals; All incoming signals should be clear. •... -
Page 6: Description
Description of the device Features The Oxygen is a mixer from Dap Audio. • 2x Stereo line or microphone (channel 1,2,6,7) • Stereo line or stereo record player (channel 3,4,5) • 7x MIC Input • Gain control • High, Mid, Low control •... -
Page 7: Frontside
Frontside 1) Line 1 /Line 2 + Peak Indicator 2) Mic 1 3) Gain range for Mic +10 / +60 dB; range for Line -10 / +40 dB 4) EQ Hi, range -15 / +15 dB 5) EQ Mid, range -15 / +15 dB 6) EQ Low, range -18 / +18 dB 7) Balance 8) PFL (Pre Fade Listening) -
Page 8: Backside
Backside Fig. 2 23) Balanced Master 1 XLR Output L/R 24) Effect Send L/R 25) Effect Return L/R 26) IEC Connector + Fuse 27) Master 2 Jack L/R 28) Booth L/R 29) PFL L/R 30) Rec L/R 31) Line 10 L/R 32) Line 11 L/R 33) Mic Input 34) Line 7... -
Page 9: Installation
Installation Remove all packing materials from the Oxygen. Check that all foam and plastic padding is removed. Connect all cables. Always disconnect from electric mains power supply before cleaning or servicing. Damages caused by non-observance are not subject to warranty. - Page 10 volume fader setting is not recognized (PRE FADER LISTEN). Once a PFL button is pressed, the master display automatically enters PFL/PGM mode. This allows you setting a signal’s correct level or making special EQ-adjustments without the need of including it in the main mix. 9.
- Page 11 Caution: Depending on the type of headphones connected to the phones jack, the Oxygen is capable of producing very high output levels via the phones output. Therefore, make sure to turn the control all the way to the left (minimum setting) before connecting the headphones.
-
Page 12: Set Up And Operation
Set Up and Operation Before plugging the unit in, always make sure that the power supply matches the product specification voltage. Do not attempt to operate a 120V specification product on 230V power, or vice versa. Set Up Set Up example... -
Page 13: Connection Cables
Connection Cables Take care of the connector cables, always holding them by the connectors and avoiding knots and twists when coiling them: This gives the advantage of increasing their life and reliability, which is always to your advantage. Periodically check that your cables are in good condition, that they are correctly wired and that all their contacts are perfectly efficient: a great number of problems (faulty contacts, ground hum, discharges, etc.) are caused entirely by using unsuitable or faulty cables. -
Page 14: Maintenance
Maintenance DAP Audio Oxygen requires almost no maintenance. However, you should keep the unit clean. Disconnect the mains power supply, and then wipe the cover with a damp cloth. Do not immerse in liquid. Do not use alcohol or solvents. -
Page 15: Product Specifications
Product Specification Model: DAP Audio Oxygen Power AC 230V-50Hz (CE) Dimensions 480 x 355 x 110 mm (LxWxH) Weight 7,46 Kg Inputs 7x Microphone (XLR balanced) 11x Stereo Line (2x gold-platet RCA unbalanced) 3x Stereo Phono with faderstart (2x gold-plated RCA unbalanced) 1x Effect return (2x RCA unbalanced) +48V Phantom Power (optional;...
