MERLIN ULTRA AT A GLANCE
Take a few moments to familiarize yourself with the
components of your Merlin ultra:
1.
Merlin ultra
2.
LCD Monitor
3.
Light ON/OFF Switch
4.
Viewing Mode button
5.
Size (Magnification) dial
6.
Merlin ultra power button
7.
LCD Brightness Control Lever
8.
X-Y table locking lever
9.
X-Y table
10. Recessed handles for carrying Merlin ultra
11. LCD monitor arm
12. Merlin ultra 5V power supply
13. Merlin ultra Base & LCD Monitor "Y" Power Cord
(style of power cord may vary based upon country)
Optional Accessories:
14. HD Pack
