ZOOM RANGE 1 (Default)
2.3x to 61.2x on 24" monitor
2.1x to 55.9x on 22" monitor
1.9x to 51.2x on 20" monitor
Steps 1-10 use optical zoom. Steps 11-16 use digital zoom.
Recommended option for best image quality.
ZOOM RANGE 2
2.3x to 104.0x on 24" monitor
2.1x to 95.0x on 22" monitor
1.9x to 87.0x on 20" monitor
Steps 1-10 use optical zoom. Steps 11-16 use digital zoom.
*Zoom range for 24" monitor is based on a 16:9 aspect ratio
*Zoom range for 22" monitor is based on a 16:9 aspect ratio
*Zoom range for 20" monitor is based on a 16:9 aspect ratio
*Zoom Ranges subject to change
LED'S
Rotate the Size dial clockwise/counter-clockwise to navigate to
the desired LED brightness. Press the Mode button once to set.
Rotate the Size dial counter-clockwise to 'Exit' and press the
Mode button to exit.
