SHOWTEC Explorer 1200 User Manual page 25

Problem Probable cause(s)
No power to the fixture
One or more
fixtures are
Primary fuse blown.
completely dead.
Fixtures reset The controller is not connected.
correctly, but all
3-pin XLR Out of the controller
respond
does not match XLR Out of the
erratically or not
first fixture on the link (i.e. signal is
at all to the
reversed).
controller.
Poor data quality
Bad data link connection
Data link not terminated with 120
Fixtures reset
Ohm termination plug.
correctly, but
Incorrect addressing of the
some respond
fixtures.
erratically or not
at all to the
controller.
One of the fixtures is defective
and disturbs data transmission on
the link.
3-pin XLR Out on the fixtures does
not match (pins 2 and 3 reversed).
Shutter closes The color wheel, gobo wheel, or a
suddenly gobo has lost its index position
and the fixture is resetting the
effect.
The power supply settings do not
No light match local AC voltage and
frequency.
Lamp missing or blown
Lamp cuts out Fixture is too hot.
intermittently.
The power supply settings do not
match local AC voltage and
frequency.
Remedy
·Check that power is switched on and
cables are plugged in.
·Replace fuse.
·Connect controller.
·Install a phase reversing cable
between the controller and the first
fixture on the link.
·Check data quality. If much lower
than 100 percent, the problem may
be a bad data link connection, poor
quality or broken cables, missing
termination plug, or a defective fixture
disturbing the link.
·Inspect connections and cables.
Correct poor connections. Repair or
replace damaged cables.
·Insert termination plug in output jack
of the last fixture on the link.
·Check address setting.
·Bypass one fixture at a time until
normal operation is regained: unplug
both connectors and connect them
directly together.
·Have the defective fixture serviced by
a qualified technician.
·Install a phase-reversing cable
between the fixtures or swap pin 2
and 3 in the fixture, that behaves
erratically.
·Contact a technician for servicing if
the problem persists.
·Disconnect fixture. Check settings
(page 9) and correct if necessary.
·Disconnect fixture and replace lamp.
·Allow fixture to cool.
·Clean fan.
·Make sure air vents at control panel
and front lens are not blocked.
·Turn up the air conditioning.
·Disconnect fixture. Check settings
(page 9) and correct if necessary.
