DMX Protocol
Channel 1 - Horizontal movement (Pan)
Push the slider up, in order to move head horizontally (PAN).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 540°and stopped at any position you wish.
Channel 2 - Pan fine 16 bit
Channel 3 - Vertical movement (Tilt)
Push the slider, up in order to move head vertically (TILT).
Gradual head adjustment from one end of the slider to the other (0-255, 128-center).
The head can be turned by 280°and stopped at any position you wish.
Channel 4 - Tilt fine 16 bit
Channel 5 – Scan Speed Adjustment
0-255
Channel 6 – Lamp ON/OFF & RESET
0-127
128-139
140-229
230-239
240-255
Channel 7 –Colorwheel
0-13
14-27
28-41
42-55
56-68
69-82
83-97
98-104
105-117
118-134
135-152
153-171
172-190
191-197
198-255
Channel 8 – Cyan
0-255
Channel 9 – Magenta
0-255
Gradual adjustment Scan Speed from fast to slow
No function
Lamp on after 3 seconds, reset
No function
Lamp off after 3 seconds
No function
Open / white
Red
Blue
Green
Orange
6000ºK Color Temperature Filter
UV Filter
Open / white
Red
Blue
Green
Orange
6000ºK Color Temperature Filter
No function
Rainbow effect from slow to fast
Gradual adjustment Cyan from 0% -100%
Gradual adjustment Magenta from 0% -100%
14
