The Audio settings

Audio Input HDMI [3, 4] Mode
Determine if the audio channels on the HDMI input shall be enabled. The HDMI input 3 and 4 have
two audio channels.
Requires user role: ADMIN
Value space: <On/Off>
On: Enable the audio channels on the HDMI input.
Off: Disable the audio channels on the HDMI input.
Example: Audio Input HDMI 3 Mode: On
Audio Input HDMI [3, 4] Level
Define the audio level of the HDMI input connector, in steps of 1 dB.
See the Audio Level tables in the Physical Interfaces Guide for the codec for a complete overview
of the menu values represented in dB.
Requires user role: ADMIN
Value space: <-24..0>
Range: Select a value from -24 to 0 dB.
Example: Audio Input HDMI 3 Level: 0
Audio Input HDMI [3..4] VideoAssociation MuteOnInactiveVideo
Enable association of a video source to an HDMI audio input.
Requires user role: ADMIN
Value space: <On/Off>
On: A video source is associated, and the audio will be muted if the associated video source is
not displayed.
Off: No video source is associated.
Example: Audio Input HDMI 3 VideoAssociation MuteOnInactiveVideo: Off
Audio Input HDMI [3..4] VideoAssociation VideoInputSource
Select the associated video input source.
Requires user role: ADMIN
Value space: <1/2/3/4/5>
Range: Select one of the video input sources.
Example: Audio Input HDMI 3 VideoAssociation VideoInputSource: 1
D14635.0 6 Profile C90 and Codec C90 Administrator Guide TC4.2, July 2011.
Copyright © 2010-2011 Cisco Systems, Inc. All rights reserved.
Web interface Advanced settings Advanced settings
Audio Input Line [1..4] Equalizer ID
Select the audio input line equalizer ID.
Requires user role: ADMIN
Value space: <1..8>
Example: Audio Input Line 1 Equalizer ID: 1
Audio Input Line [1..4] Equalizer Mode
Set the audio input line equalizer mode.
Requires user role: ADMIN
Value space: <On/Off>
Example: Audio Input Line 1 Equalizer Mode: Off
Audio Input Line [1..4] VideoAssociation MuteOnInactiveVideo
Enable association of a video source to a Line audio input.
Requires user role: ADMIN
Value space: <On/Off>
Example: Audio Input Line 1 VideoAssociation MuteOnInactiveVideo: Off
Audio Input Line [1..4] VideoAssociation VideoInputSource
Select the associated video input source.
Requires user role: ADMIN
Value space: <1/2/3/4/5>
Example: Audio Input Line 1 VideoAssociation VideoInputSource: 1
Audio Input Line [1..4] Channel
Define whether the Audio Line input is a mono signal or part of a multichannel signal.
Requires user role: ADMIN
Value space: <Left/Right/Mono>
Example: Audio Input 1 Channel: Left
34
Password protection
Range: Select EqualizerID 1 to 8.
On: Enable the equalizer for the audio input line.
Off: No equalizer.
On: A video source is associated, and the audio will be muted if the associated video source is
not displayed.
Off: No video source is associated.
Range: Select one of the video input sources.
Left: The Audio Line input signal is the left channel of a stereo signal.
Right: The Audio Line input signal is the right channel of a stereo signal.
Mono: The Audio Line input signal is a mono signal.
