Operator's Manual
Field Trimmer
HYFT56
Your weed trimmer has been engineered and manufactured to our high standard for dependability, ease of
operation, and operator safety.
To reduce the risk of injury, the user must read and understand the operator's manual BEFORE
using this product.
Thank you for your purchase.
www.hyundaipowerequipment.co.uk
Licensed by Hyundai Corporation, Korea
P/N 19989

Advertisement

loading

Related Manuals for Hyundai HYFT56

Summary of Contents for Hyundai HYFT56

  • Page 1 Your weed trimmer has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. To reduce the risk of injury, the user must read and understand the operator’s manual BEFORE using this product. Thank you for your purchase. www.hyundaipowerequipment.co.uk Licensed by Hyundai Corporation, Korea P/N 19989...
  • Page 2 Operator's Manual Hyundai HYFT56 Field Trimmer General Safety Rules .................
  • Page 3 Operator's Manual Hyundai HYFT56 Field Trimmer This book is written for a person with some mechanical abil- ity. Like most service books, not all the steps are described. Steps on how to loosen or tighten fasteners are steps anyone To prevent accidental starting when setting up, can follow with some mechanical ability.
  • Page 4 Operator's Manual Hyundai HYFT56 Field Trimmer struck by low hanging branches, twigs, or other objects, have stopped. Remove the wire from the spark plug. which may be unnoticed by the operator. • If the trimmer should start to vibrate abnormally, stop the •...
  • Page 5 Operator's Manual Hyundai HYFT56 Field Trimmer is running except when specifically recommended by the manufacturer. • Handle fuel with care; it is highly flammable. • Keep the trimmer in safe working condition. Check all • Use an approved container. fasteners at frequent intervals for proper tightness.
  • Page 6 Operator's Manual Hyundai HYFT56 Field Trimmer Many of the following symbols are located on your unit or on literature supplied with the product. Before you operate the unit learn and understand the purpose for each symbol. SLOW FAST ENGINE S TOP...
  • Page 7 Operator's Manual Hyundai HYFT56 Field Trimmer Indicates WARNING, DANGER, or CAUTION. Read operator’s manual before operating this machine. Failure to follow directions could result in serious injury. Thrown objects. Keep bystanders at least 50 ft (15m) away. Do not use if children are present.
  • Page 8 Operator's Manual Hyundai HYFT56 Field Trimmer Engine Displacement ........160cc Oil Capacity .
  • Page 9 Operator's Manual Hyundai HYFT56 Field Trimmer Read and follow the assembly and adjustment instructions. Do not discard any parts or materials until the unit is as- (1) Utility Knife to Cut Carton sembled. (1) Oil Funnel (1) Torque Wrench to Check Fastener Tightness...
  • Page 10 Operator's Manual Hyundai HYFT56 Field Trimmer For the best performance and satisfaction from this qual- ENGINE DOES NOT CONTAIN OIL OR PETROL WHEN SHIPPED ity product, please review the following checklist before you operate the trimmer: See the engine manufacturer’s instructions for the type of •...
  • Page 11 Operator's Manual Hyundai HYFT56 Field Trimmer Debris thrown from the trimmer can result in foreign objects being thrown into eyes, which can cause severe eye damage. Always wear CE compliant safety glasses or Primer eye shields when operating the trimmer.
  • Page 12 Operator's Manual Hyundai HYFT56 Field Trimmer Handle Never run the engine indoors or in a poorly ventilated area. Engine exhaust contains carbon monoxide, an odourless and deadly gas. Keep hands, feet, hair and loose clothing away from the trimmer and any moving parts on the engine.
  • Page 13 Operator's Manual Hyundai HYFT56 Field Trimmer Debris such as sticks, gravel, and rocks can be thrown with sufficient force to cause personal injury or property damage. • Set the throttle control in the FAST position. The faster the engine runs, the faster the trimmer head will rotate. If the weeds or grass are tall and thick, operate the trimmer at a slower walking speed.
  • Page 14 Operator's Manual Hyundai HYFT56 Field Trimmer www.hyundaipowerequipment.co.uk...
  • Page 15 Operator's Manual Hyundai HYFT56 Field Trimmer Check Engine Oil √ Level Check Trimmer Lines √ Check Trimmer Head √ Engagement Engine/Machine √ Cleaning Check Nuts and Bolts √ Check Spark Plug √ Change Engine Oil √ Service Air Filter √...
  • Page 16 Operator's Manual Hyundai HYFT56 Field Trimmer Use the following maintenance section to keep your unit in good operating condition. All the maintenance information for Oil Drain Plug the engine is in the “Engine Operator’s Manual”. Before you start the engine, read this manual.
  • Page 17 Operator's Manual Hyundai HYFT56 Field Trimmer When the trimmer line becomes worn to half the original length, replace the trimmer line. For the best performance, use a heavy gauge 4mm [0.155” (inch)] trimmer line. 1. Stop the engine. Wait for all moving parts to stop.
  • Page 18 Operator's Manual Hyundai HYFT56 Field Trimmer Trimmer Housing Before you remove the drive belt, disconnect the wire from the spark plug. To replace the drive belt, the trimmer head and shield must be removed as follows. 1. Remove the two fasteners that hold the rear of the shield to the trimmer housing.
  • Page 19 Operator's Manual Hyundai HYFT56 Field Trimmer Remove the spark plug from the cylinder. Pour 28 grams / 1 ounce of oil into the cylinder. Slowly pull the recoil-start handle so that the oil will protect the cylinder. Install a new spark plug in the cylinder. Pull recoil-start handle slowly a few times to distribute oil.
  • Page 20 Operator's Manual Hyundai HYFT56 Field Trimmer Engine does not start Spark plug wire disconnected Connect spark plug. Engine not primed Prime engine. Defective or incorrectly gapped spark plug Inspect or replace spark plug. Fuel tank empty or low Add fuel.
  • Page 21 Operator's Manual Hyundai HYFT56 Field Trimmer Trimmer vibrates Set screws for trimmer head is loose Tighten set screw with T-handle wrench. Trimmer line lengths are substantially di erent Adjust trimmer line to approximately equal lengths. Loose nuts or bolts Check all bolts and nuts, including engine bolts.
  • Page 22 Operator's Manual Hyundai HYFT56 Field Trimmer A100535 Engine A100536 Pulle y,Engine A100537 Lock Washe r, ø10 A100538 Bolt Bolt ,Hex Head 3/8-24x1.0 A100539 Belt, Trimmer Bolt A100540 Screw ,Engine 3/8-16x1.0 A100541 Upper Handle A100542 Leve r, Stop Lower Handle A100543...
  • Page 23 Operator's Manual Hyundai HYFT56 Field Trimmer A100556 Spacer A100557 Washe r, Spring A100458 Bolt, M8x16 A100558 Assembl y, Axle & Bracket A100559 Wheel & Tyre Bearing A100560 Nut, M10 A100462 Frame, Trimmer A100561 Spacer Assembl y, A100562 Jackshaft Screw A100563...
  • Page 24 Operator's Manual Hyundai HYFT56 Field Trimmer Nut, M10x1.25 A100462 Washe r, Flat ø10 A100577 Pulle y, Cutting Head A100578 Spacer A100579 Wrap Weed, Upper BLK A100580 Screw A100581 Shaft, Cutting Head A100582 Wrap Weed, Lower BLK A100583 Screw A100584 Wrench, T-Handle...
  • Page 25 Operator's Manual Hyundai HYFT56 Field Trimmer NOTES _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ _______________________________________________________________________________________________________ www.hyundaipowerequipment.co.uk...

  • Page 26: Declaration Of Conformity

    Operator's Manual Hyundai HYFT56 Field Trimmer DECLARATION OF CONFORMITY Genpower Ltd con rms that this Hyundai product conforms to the following CE directives: 2006/42/EC Machinery directive 2004/108/EC EMC directive 2000/14/EC Noise emissions directive 97/68/EC NRMM Emissions directive www.hyundaipowerequipment.co.uk...
  • Page 27 Operator's Manual Hyundai HYFT56 Field Trimmer www.hyundaipowerequipment.co.uk...
  • Page 28 GENPOWER LTD Unit 1, Dowty Park, Thornton Ind. Est. Milford Haven, UNITED KINGDOM, SA73 2RS T: +44 (0) 1646 663 848 F: +44 (0) 1646 663 856 e: info@hyundaipowerequipment.co.uk www.hyundaipowerequipment.co.uk...
