  • Page 2: Table Of Contents

    CONTENTS Section Description Page N o’s 1. SAFETY 3 - 6 2. MACHINE PARTS 3. ASSEMBLY PROCEDURE 8 - 9 4. OPERATING PROCEDURES 10- 11 5. MAINTENANCE 12 -14 6. TROUBLESHOOTING 7. STORAGE 8. SPECIFICATION 9. GENPOWER CONTACT DETAILS 10. DECLARATIONS of CONFORMITY Page 2...

  • Page 3: Safety

    1. SAFETY. 1.1. The operator of the machine; 1.1.1. Is responsible for and has a duty of care in making sure that the machine is operated safely and in accordance with the instructions in this user manual. 1.1.2. Should never leave it in a condition which would allow an untrained or unauthorised person/s to operate this machine.
  • Page 4 1.3. Carbon Monoxide 1.3.1. Carbon monoxide is a colourless and odourless, inhaling this gas can cause death as well as serious long term health problems such as brain damage. 1.3.2. The symptoms of Carbon monoxide poisoning can include the following; 1.3.2.1.
  • Page 5 1.6.4. When replacing the spool line, always use certified replacement sourced from the manufacturer. Only use genuine Hyundai spare parts. Page 5...
  • Page 6 1.6.5. Under no circumstances should you ever take the product apart or alter it in any way even if the item is faulty. You may damage or cause further harm by taking the product apart and you will void your warranty in doing so. 1.6.6.

  • Page 7: Machine Parts

    2. MACHINE PARTS Spark Plug Safety Trigger Air Filter Throttle Lock Choke Lever Handle Starter Pull Cord Clamp Primer Bulb Spool head Fuel Tank Trimmer guard Throttle Trigger Fuel Mixing Container Ignition Switch Belt/Harness Accessories: 1 x Trimmer guard; 1 x Belt/Harness; 1 x Fuel Mixing Container; 1 x Allen key 4mm: 1 x Allen key 5mm &...

  • Page 8: Assembly Procedure

    3. ASSEMBLY PROCEDURE Anti-vibration systems do not guarantee that you will not sustain white finger disease or carpal tunnel syndrome. Therefore, continual and regular users should monitor closely the condition of their hands and fingers. If any of the above symptoms appear, seek medical advice immediately.
  • Page 9 3.3. Trimmer guard assembly. 3.3.1. Insert the trimmer guard. 3.3.2. Tighten screw with 5mm Allen key. 3.4. Replacing the spool line. 3.4.1. Remove bump head knob by turning anti- clockwise. 3.4.2. Remove the spool and spring from spindle. 3.4.3. Measure approximately 26 feet (8 metres) of line, then thread one end through the hole on the spool.

  • Page 10: Operating Procedures

    4. OPERATING PROCEDURES The trimmer is equipped with a two stroke engine. Always run the engine on unleaded fuel mixed with two stroke oil N.B. see specification section. Always carry out fueling processes outside. Always wear correct Personal Protective Equipment (PPE) when using machine Minimum Recommended PPE.
  • Page 11 4.3.4. Pull the recoil starter briskly, taking care to keep the handle in your grasp and not allowing it to snap back. 4.3.5. When you hear the engine wants to start, return choke lever to ON position. Then briskly pull the recoil starter again. If engine does not start repeat procedure from 4.3.2 to 4.3.5.

  • Page 12: Maintenance

    5. MAINTENANCE 1 – The cutting attachment may spin during carburetor adjustments 2 – The cutting attachment should under no circumstances rotate when the engine is idling. 3 – Never start the engine without the complete clutch cover and tube assembled! Otherwise the clutch can come loose and cause personal Injury.
  • Page 13 5.3. Cleaning the air filter. 5.3.1. Remove the air filter cover and the filter. 5.3.2. Rinse it in warm soapy water. Check that the filter is dry before reassembly. An air that has been used for some time cannot be cleaned completely. 5.3.3.
  • Page 14 5.7.2. Air must circulate freely around engine and over cooling fins on cylinder head to prevent overheating. 5.7.3. Every 100 hours of operation, or once a year (more often if conditions require); 5.7.3.1. Clean fins and external surfaces of engine of dust. 5.7.3.2.

  • Page 15: Troubleshooting

    6. TROUBLESHOOTING. 6.1. Engine Troubleshooting - N.B. all corrective actions should be carried out by suitably qualified person/s. Problem Check Status Cause Remedy Fuel filter blocked Clean or replace. Fuel line blocked or Clean or replace. Fuel at No fuel at clogged Carburetor Carburetor...

  • Page 16: Storage

    The machine is not going to be used for some time i.e. longer than 3 months. 7.1.1.2. Storing machine for the winter. Failure to do so may cause corrosion to the carburetor. 8. SPECIFICATION HYTR2650 Air cooled, two stroke, single Engine type cylinder petrol engine Max output 1.2W @ 7500 rpm...

  • Page 17: Genpower Contact Details

    9. GENPOWER CONTACT DETAILS 9.1. Postal address; Genpower Limited, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK. 9.2. Telephone contact number; Office +44 (0) 1646 687880 9.3. Email contacts; Technical service@genpower.co.uk 9.4. Web site; www.hyundaipowerequipment.co.uk Page 17...

  • Page 18: Declarations Of Conformity

    10. DECLARATIONS of CONFORMITY 10.1. Genpower Ltd confirms that these Hyundai products conform to the following CE Directives; 10.1.1. 2006/42/EC Machinery Directive 10.1.2. 2004/108/EC EMC Directive 10.1.3. 2000/14/EC Noise Emissions Directive 10.1.4. 97/68/EC NRMM Emissions Directive Page 18...
  • Page 19 Page 19...
