CARRIER SA
SCHEME 6 : Air Cooled Chillers
BASIC BOARD
Address = 1
Channel 01
AI
COOL LWT
Channel 02
AI
COOL EWT
Channel 03
AI
CHWSTEMP
Channel 04
AI
OAT
Channel 05
AI
Channel 06
AI
DP A
Channel 07
AI
SP A
Channel 08
AI
Channel 09
AI
Channel 10
AI
EXT VDC
Channel 11
MUX DI
11- bit 0
DI
onoff sw
11 - bit 1
DI
spt sw
11 - bit 2
DI
hc sw
11 - bit 3
DI
lim sw
11 - bit 4
DI
lock 1
11 - bit 5
DI
elec box
cond_flow
11 - bit 6
DI
pump_def
11 - bit 7
DI
Channel 19
DO
CPUMP 1
Channel 20
DO
CPUMP 2
Channel 21
DO
Channel 22
DO
OIL HTRA
Channel 23
DO
COOL HTR
Channel 24
DO
ALARM A
Channel 25
DO
REFA ISO
Channel 26
DO
SAFE ALM
EXV BOARD
Address = 29
Channel 29
EXV ST A
Channel 33
Channel 37
AI
MTQ RESA
Channel 38
AI
-
Downloaded from
www.Manualslib.com
USER'S GUIDE FOR
30GX&HX PRO_DIALOG 4 V.2
1 compressor, Aux Board, No Varifan
SCPM BOARD #1
Address =84
Channel 84
DO
CP A1
Channel 85
CPA1 MUX
85 - bit 0
DO
cpa1 mc1
85 - bit 1
DO
cpa1 mc2
85 - bit 2
DO
cpa1 ols
85 - bit 3
DO
a1 ldr 1
85 - bit 4
DO
a1 ldr 2
85 - bit 5
DO
oilpmp a
Channel 86
DO
CPA1 PUL
Channel 87
AI
CPA1 CUR
1
Channel 88
AI
CPA1 OP
Channel 89
AI
CPA1 ECP
Channel 90
AI
CPA1 DGT
Channel 91
AI
CPA1 TMP
Channel 92
AI
CPA1 STA
Channel 93
AI
-
Channel 94
AI
-
Channel 27-28: virtual
manuals search engine
ECG-UG-02-002
Page: 87 / 98
Rev: Original
AUXILIARY BOARD # 1
Address = 49
Channel 49
MUX FAN1
Ch 49 bit-0
DO
fan a1
Ch 49 bit-1
DO
fan a2
Ch 49 bit-2
DO
fan a3
Ch 49 bit-3
DO
fan a4
Ch 49 bit-4
DO
-
Ch 49 bit-5
DO
-
Ch 49 bit-6
DO
-
Ch 49 bit-7
DO
-
