Carrier Pro-Dialog CONTROL 4 User Manual page 71

CONFIGURATION SCREEN
TABLE NAME: OCCDEFCS / OCCPC01S and OCCPC02S
DESCRIPTION
1 Timed Override Hours
2 Period 1 DOW (MTWTFSSH)
3
4
5 Period 2 DOW (MTWTFSSH)
6
7
8 Period 3 DOW (MTWTFSSH)
9
10
11 Period 4 DOW (MTWTFSSH)
12
13
14 Period 5 DOW (MTWTFSSH)
15
16
17 Period 6 DOW (MTWTFSSH)
18
19
20 Period 7 DOW (MTWTFSSH)
21
22
23 Period 8 DOW (MTWTFSSH)
24
25
TABLE NAME: HOLIDAY / HOLDY01S to HOLDY016S
DESCRIPTION
Holiday Start Month
