Carrier Pro-Dialog CONTROL 4 User Manual page 68

TABLE NAME: MODES
DESCRIPTION
1 OPERATING MODES
2 Startup Delay in Effect
3 Second Setpoint in Use
4 Reset in Effect
5 Demand Limit Active
6 Ramp Loading Active
7 Low Source Protection
8 Low Cooler Suction Cir A
9 Low Cooler Suction Cir B
10 Low Dis Superheat Cir A
11 Low Dis Superheat Cir B
12 High Pres Override Cir A
13 High Pres Override Cir B
14 High Current Over Cir A
15 High Current Over Cir B
16 Reclaim Active?
17 Cooler Heater Active?
18 Cooler Pumps Rotation?
19 Pump Periodic Start?
20 Night Capacity Active?
21 System Manager Active?
22 Master Slave Active?
Downloaded from www.Manualslib.com
CARRIER SA
30GX&HX PRO_DIALOG 4 V.2
PIC TABLE TYPE : 11H, instance 8
NOT TO BE DISCLOSED TO PERSONS OUTSIDE CARRIER ORGANIZATION
manuals search engine
USER'S GUIDE FOR
STATUS UNITS
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
Yes/No -
C
©
.
ARRIER S A
ECG-UG-02-002
Page: 67/98
Rev: Original
POINTS FORCEABLE
Mode[07] N
Mode[08] N
Mode[09] N
Mode[10] N
Mode[11] N
Mode[12] N
Mode[13] N
Mode[14] N
Mode[15] N
Mode[16] N
Mode[17] N
Mode[18] N
Mode[19] N
Mode[20] N
Mode[21] N
Mode[22] N
Mode[23] N
Mode[24] N
Mode[25] N
Mode[26] N
Mode[27] N
