Carrier Pro-Dialog CONTROL 4 User Manual page 64

DISPLAY SCREEN
TABLE NAME: CIRCA_D
DESCRIPTION
1 CIRCUIT A DISCRETE
2
3 Compressor 1 Output
4
5
6
7 Compressor 2 Output
8
9
10
11 Cir A, Loader 1 Output
12 Cir A, Loader 2 Output
13 Cir A, Oil Heater Output
14 Cir A, Oil Level Input
15 Cir A, Oil Pump Output
16 Cir A Refrig Isolate Out
17
18 FANS OUTPUT
19 Fan Output DO # 1
20 Fan Output DO # 2
21 Fan Output DO # 3
22 Fan Output DO # 4
23 Fan Output DO # 5
24 Fan Output DO # 6
25 Fan Output DO # 7
26 Fan Output DO # 8
27 Fan Staging Number
DISPLAY SCREEN
TABLE NAME: CIRCB_AN
DESCRIPTION
1 CIRCUIT B ANALOG VALUES
2.
3 Percent Total Capacity
4 Discharge Pressure
5 Suction Pressure
6 Oil Pressure Cp1
7 Oil Pressure Cp2
8 Oil Press Difference Cp1
9 Oil Press Difference Cp2
10 Economizer Pressure Cp1
11 Economizer Pressure Cp2
12 Saturated Condensing Tmp
13 Saturated Suction Temp
Downloaded from www.Manualslib.com
CARRIER SA
30GX&HX PRO_DIALOG 4 V.2
PIC TABLE TYPE : 11H, instance 3
Cp1 Mtr Cool Solenoid 1
Cp1 Mtr Cool Solenoid 2
Cp1, Oil Solenoid Out
Cp2 Mtr Cool Solenoid 1
Cp2 Mtr Cool Solenoid 2
Cp2, Oil Solenoid Out
PIC TABLE TYPE : 11H, instance 4
NOT TO BE DISCLOSED TO PERSONS OUTSIDE CARRIER ORGANIZATION
manuals search engine
USER'S GUIDE FOR
STATUS UNITS
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
Low/High -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
On/Off -
0 - 8 -
STATUS UNITS
0 - 100 %
nnn.n psi
nnn.n psi
nnn.n psi
nnn.n psi
nnn.n psi
nnn.n psi
nnn.n psi
nnn.n psi
±nnn.n °F
±nnn.n °F
C
©
.
ARRIER S A
ECG-UG-02-002
Page: 63/98
Rev: Original
POINTS FORCIBLE
CP_A1 N
cpa1_mc1 N
cpa1_mc2 N
cpa1_ols N
CP_A2 N
cpa2_mc1 N
cpa2_mc2 N
cpa2_ols N
ldr_1_a N
ldr_2_a N
oil_h_a N
oil_l_a N
oilpmp_a N
refa_iso N
fan_a1 N
fan_a2 N
fan_a3 N
fan_a4 N
fan_a5 N
fan_a6 N
fan_a7 N
fan_a8 N
FAN_ST_A N
POINTS FORCEABLE
CAPB_T N
DP_B N
SP_B N
CPB1_OP N
CPB2_OP N
DOP_B1 N
DOP_B2 N
CPB1_ECP N
CPB2_ECP N
SCT_B N
SST_B N
