3.2 - Basic Board

The PD4 - Basic board is 24VAC power supplied. It contains 8 Discrete Inputs (Switch type), 8 Digital Outputs (5
triacs and 3 relays), 10 Analog Inputs (five thermistors and four pressure transducers) and 1 analog input (0-10
Vdc) . See the schemes in Appendix E. The software is contained in a Flash EPROM (downloadable only with
Downloader). All the setpoints, runtime and configuration parameters are contained in an EEPROM (data
storage at power down).
TERMINAL
3.2 - CCN/Clock Option Board (factory installed)
The PD4 - Global chiller controller has a small option board that can be connected to the Basic Board via a
single 10 pin header and 4 metal standoff. This option board contains one RS-485 driver for CCN
communication, a real time clock and super cap for two weeks backup. There are two connectors for CCN. One
is a 3 pin screw connector ( 1= + signal, 2 = ground signal, 3 = - signal) and the other is a 6 pins phone jack.
Downloaded from www.Manualslib.com
CARRIER SA
CHANNEL
J6 1 Cooling leaving water temperature
J6 2 Cooling entering water temperature
J6 3 Master/Slave common piping fluid temperature
J6 4 Outside Temperature
J6 4 Condenser leaving water temperature
J6 Condenser entering water temperature
5
J7A 6 Circuit A discharge pressure
J7B 7 Circuit A suction pressure
J7C 8 Circuit B discharge pressure
J7D 9 Circuit B suction pressure
J8 10 0-10 VDC setpoint reset signal or demand limit signal
J4 11 Remote Control switch status
J4 12 Dual setpoint switch
J4 13 Heat Cool switch
J4 13 Heat Reclaim switch
J4 14 Demand limit switch
J4 & J5 15 a & 15 b Cooler flow switch & customer interlock (lock_1)
J5 16 a & 16 b Electrical box thermostat & network power reverse
phase detection
J5 17 Condenser flow switch
J5 18 Cooler pump default
J2 19 Cooler Pump #1
J2 20 Cooler Pump #2
J2 21 Condenser Pump
J2 22 Oil Heater Circuit A
J2 23 Oil Heater Circuit B
J3 24 Alarm Circuit A
J3 25 Alarm Circuit B
J3 26 Safety Critical Signal (for Contactor Failure)
NOT TO BE DISCLOSED TO PERSONS OUTSIDE CARRIER ORGANIZATION
manuals search engine
USER'S GUIDE FOR
30GX&HX PRO_DIALOG 4 V.2
FUNCTION
© C .
ARRIER S A
ECG-UG-02-002
Page: 10/98
Rev: original
UNIT TYPE
All
All
Master/Slave
Air cooled
Water cooled and heat pump
Water cooled and heat pump
All
All
All
All
All
All
All
Heat machine
All excepted heat machine
All
All
All
All excepted air cooled without
reclaim option
All
All
All
All excepted air cooled without
reclaim option
Air cooled
Air cooled
All
All
All
