FUNCTIONS
Maximum Condensing Temperature Override
Maximum Current Override
Close Control Select
FSM & CSM II Control
Two units Master/Slave Control
** : require a CCN/Clock board
All Pro-Dialog controls can work either autonomously or they can be interfaced with the Carrier Comfort Network
(CCN). In the later case a communication data cable is used to connect the unit to the CCN communication bus.
When Pro-Dialog system operates autonomously it retains all of its own control capabilities but does not offer
the functionality of the CCN network.

2.2 - SOFTWARE REFERENCE NUMBER

This software is referenced under the 15 digits software reference number:
The two last digits (XX) provides the software version (e.g. 2.0).
15 digits reference number can be displayed in the CCN configuration Ctrl_ID table through the Building
Supervisor, the Network Service Tool or the 30GX&HX Downloader.
Unit Main Interface Configuration Menu allows to display the software version: item #13, user 1 menu.

2.2 - Abbreviations Used

In this manual, the refrigeration circuits are called circuit A and circuit B. The compressors in circuit A are
labeled A1, and A2. Those in circuit B are B1 and B2.
