Carrier Pro-Dialog CONTROL 4 User Manual page 66

DISPLAY SCREEN
TABLE NAME: OPTIONS
DESCRIPTION
1 UNIT DISCRETE IN
2 Remote On/Off Switch
3 Remote Heat/Cool Switch
4 Remote Reclaim Switch
5 Remote Setpoint Switch
6 Limit Switch Status
7 Interlock Status
8 Pump Run status
9 Condenser Flow Status
10 Electrical Box Thermostat
11
12 UNIT DISCRETE OUT
13 Cooler Pump #1 Command
14 Cooler Pump #2 Command
15 Rotate Pumps Now?
16 Condenser Pump Command
17 Cooler Heater Command
18 Critical Alarm Signal
19
20 UNIT ANALOG
21 Cooler Entering Fluid
22 Cooler Leaving Fluid
23 Condenser Entering Fluid
24 Condenser Leaving Fluid
25 CHWS Temperature
26 External 0-10Vdc Signal
27 Current Cond Setpoint
28 Chiller Total Current
1: Cooler pump control. This item can be forced On or Off if the unit is in CCN mode and if the CHIL_S_S is
disabled. If the unit is not in CCN mode the forced value shall be unused and the regular calculation shall be
used. Forced value and force code shall appear in the OPTIONS Points Display table only if the unit is under CCN
control and if CHIL_S_S is disabled.
If PUMP#1 is forced, no force shall be allowed on PUMP_2 and vice versa.
2: Condensing Setpoint. This item can be forced. If the unit is in CCN mode, the forced value shall be used instead
of the real control point calculation. If the unit is not in CCN mode the forced value shall be unused and the
regular calculation shall be used. Forced value and force code shall appear in the OPTIONS Points Display table
only if the unit is under CCN control.
3: Condenser pumpcontrol. This item can be forced On but not Off. If the unit is in CCN mode, the forced value shall
be used instead of regular pump control point. If the unit is not in CCN mode the forced value shall be unused and
the regular calculation shall be used. Forced value and force code shall appear in the OPTIONS Points Display
table only if the unit is under CCN control.
4: Electrical box Thermostat. This item indicates the electrical box thermostat and network power reverse phase
detection status (wired internally in series 16a and 16b on PD4-BASIC BOARD). These contacts, when opened
will prevent the unit from starting.
5: This output is energized when a contact failure is reported by any SCPM board
