Service 3 Configuration From Service Tool - Carrier Pro-Dialog CONTROL 4 User Manual

4.2.4.5 - Service 3 configuration table from Service Tool
The Network Service tool allows to view and modify the service configuration table MAINCFG. Unit should be
stopped and under CCN Operating Type control.
TABLE NAME: MAINTCFG
DESCRIPTION
1 MAINTENANCE CONFIG
2
3 Servicing Alert
4
5 Refrigerant Charge Ctrl
6 Water Loop Control
7 Air Exchanger Control
8
9 CPump 1 Ctl Delay (days)
10 CPump 2 Ctl Delay (days)
11 HPump Ctrl Delay (days)
12 Water Filter Ctrl (days)
13 A1 Oil Filter Ctl (days)
14 A2 Oil Filter Ctl (days)
15 B1 Oil Filter Ctl (days)
16 B2 Oil Filter Ctl (days)
4.2.4.6 - Service 3 configuration table from main interface
The main interface allows to view and modify the service configuration table MAINCFG. Unit should be stopped
and service password or factory password are required.
ITEM #
0
1
2[1]
3[1]
4[1]
5[1]
6[1]
7[1]
8[1]
9[1]
10[1]
11[1]
12[1]
This table is used for service maintenance alert and not available today.
