4.2.3 - Factory configuration

4.2.3.1 - Factory configuration from Service Tool

The Network Service tool allows to view and modify the factory configuration (table FACTORY in 'Modify
Controller').
TABLE NAME: FACTORY
DESCRIPTION
1 Chiller Type
2 Circuit A Fan Stages Num
3 Circuit B Fan Stages Num
4 Varifan or W. Valves Sel
5 Economizer Select
6 Large Bd Oil Transducers
7 Comp A1 Must Trip Amps
8 Comp A2 Must Trip Amps
9 Comp B1 Must Trip Amps
10 Comp B2 Must Trip Amps
11 Reclaim Sensor Select
12 Air Cooled Reclaim Sel
13 Evaporator Number Pass
14 Cooler LWT On Circuit A
15 Cooler Heater Select
16 Factory Password
17 EXV A Maximum Steps Numb
18 EXV B Maximum Steps Numb
19 Motor Cool. TQ Feedback
20 PD4 Aux Boards Select
Parameters from 1 to 16 in version 1.x are the same than those in the new version 2.X.
For Retrofit from verson 1.x to the new 2.x, it is better to write down in a paper, configuration items
from 1 to 16. Use Service Tool to upload all the configuration from version 1 (example address 1).
Then use address search function to change the address to 2 before downloading the new software
version 2.x. Use Service Tool to add a new controller with a different addresse (example address 1 for
version 1 and address 2 for version 2). Once Upload configuration is done, fill factory configuration in
FACTORY table and then download this.
1. 1 = air cooled.
2. 0 = no fan
< 4 = each DO output of the 4xDO board support 1 fan .
> 5 = DO # 1 and DO # 2 support 1 fan each.
nb : these fans are not controlled by a varifan.
For pro_dialog 4 Auxiliary board select, each DO output of the Auxiliary board support 1 fan
Downloaded from www.Manualslib.com
CARRIER SA
30GX&HX PRO_DIALOG 4 V.2
PIC TABLE TYPE : 10H, instance 1
STATUS
1,2,3
0 to 8
0 to 8
0/1/2/3/4
Yes/No
Yes/No
0 to 560
0 to 560
0 to 560
0 to 560
Yes/No
Yes/No
1 to 3
Yes/No
Yes/No
0 to 150
1500/15000
1500/15000
Yes/No
Yes/No
2 = water cooled .
DO # 3 support 2 fans
DO # 4 support 1 fan if circuit has 5 fans max
DO # 4 support 2 fans if circuit has 6 fans max
DO # 4 support 3 fans if circuit has 7 fans max
DO # 4 support 4 fans if circuit has 8 fans max
