5 - CCN ALARM MESSAGES

The Building Supervisor displays current alarms messages and their return to normal provided that the CCN table
ALARMDEF has been correctly configured.
The Network Service Tool Diagnostic Menu allows to display 5 current alarms messages (even if the ALARDEF table
is not configured).
The following gives the messages that shall be displayed by the Building Supervisor or from main interface.
Alarm 1
Alarm 2
Alarm 3
Alarm 4
Alarm 5
Alarm 6
Alarm 7
Alarm 8
Alarm 9
Alarm 10
Alarm 11
Alarm 12
Alarm 13
Alarm 14
Alarm 15
Alarm 16
Alarm 17
Alarm 18
Alarm 19
Alarm 20
Alarm 21
Alarm 22
Alarm 23
Alarm 24
Alarm 25
Alarm 26
Alarm 26
Alarm 27
Alarm 28
Alarm 29
Alarm 30
Alarm 31
Alarm 32
Alarm 33
Alarm 34
Alarm 35
Alarm 36
Alarm 37
Alarm 38
Alarm 39
Alarm 40
Alarm 41
Alarm 42
Alarm 43
Alarm 44
Alarm 45
Alarm 46
Downloaded from www.Manualslib.com
CARRIER SA
30GX&HX PRO_DIALOG 4 V.2
Cooler Entering Thermistor
Cooler Leaving Thermistor
Condenser Entering Thermistor
Condenser Leaving Thermistor
Reclaim Condenser Entering Thermistor
Reclaim Condenser Leaving Thermistor
OAT Thermistor
MASTER/Slave Common Fluid Thermistor
Compressor A1 Discharge Gas Temperature Thermistor
Compressor A2 Discharge Gas Temperature Thermistor
Compressor B1 Discharge Gas Temperature Thermistor
Compressor B2 Discharge Gas Temperature Thermistor
0-10V Reset/Limit Input
Circuit A Discharge Transducer
Circuit B Discharge Transducer
Circuit A Suction Transducer
Circuit B Suction Transducer
Compressor A1 Oil Transducer
Compressor A2 Oil Transducer
Compressor B1 Oil Transducer
Compressor B2 Oil Transducer
Compressor A1 Economizer Transducer
Compressor A2 Economizer Transducer
Compressor B1 Economizer Transducer
Compressor B2 Economizer Transducer
Circuit A Remote Discharge Pressure Transducer
Circuit A Reclaim Pumpdown Pressure Transducer
Circuit B Reclaim Pumpdown Pressure Transducer
Circuit A Motor Cooling TQ feedback Sensor Failure
Circuit B Motor Cooling TQ feedback Sensor Failure
Loss of communication with Screw Compressor Board 1
Loss of communication with Screw Compressor Board 2
Loss of communication with Screw Compressor Board 3
Loss of communication with Screw Compressor Board 4
Loss of communication with EXV Board 1
Loss of communication with Fans Board 1
Loss of communication with Fans Board 2
Loss of communication with 4xAI_2xAO or Aux Type 1 Board
Loss of communication with Reclaim or Cooler Heater Board
Loss of communication with CCN / Clock Board
Electrical Box Thermostat or reverse phase detection Failure
Unit is in CCN emergency stop
Initial factory configuration required
Illegal configuration
Circuit A High Pressure
Circuit B High Pressure
Compressor A1 Oil Solenoid Failure
