MAGNETIC SWIPE READER

The DPP-350 has a built-in magnetic card reader. The card reader
incorporates a (3)-track magnetic read head requiring a single swipe to read
field data from all three tracks.
Magnetic Strip
( Face this direction )
The reader's magnetic head faces towards the front of the printer.
When placing the card into the reader, the magnetic strip must be facing
as show in the figure above.
inner base of the reader to ensure that the magnetic strip passes over the
read head evenly.
When swiping the card through the reader, use an even consistent motion
from start to finish. The speed of swiping can vary however the speed
must be consistent from start to finish of the swipe in order to accurately
read card data.
User Notes:
To use the magnetic card reader feature, special software must be used to
read and process the card information. If you do not have card reading
software, please consult your reseller to find out if this software is available
or contact Infinite Peripherals for recommendations on compatible third
party software solutions.
Keep the bottom edge of the card flat on the
Card Swipe Direction
Magnetic Card Reader
USER MANUAL 21
