X100 SERIES
Quick Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X100 Series and is the answer not in the manual?

Questions and answers

Related Manuals for XVision X100 Series

Summary of Contents for XVision X100 Series

  • Page 1 X100 SERIES Quick Guide...

  • Page 2: Table Of Contents

    X100 Series Quick Guide QUICK GUIDE CONTENTS INTRODUCTION....................3 i Overview ......................3 ii Features ......................3 Standard Features across the Range ............... 3 Additional Features ..................4 iii Minimum System Requirements ..............5 iv Notes on Installation ................... 6 INSTALL &...

  • Page 3: Introduction

    X100 Series Quick Guide i OVERVIEW This user guide explains how to operate your camera from a computer. Read this manual completely and carefully before you operate the device. ii FEATURES STANDARD FEATURES ACROSS THE RANGE The following are features of the X100 IP Camera Series: •...

  • Page 4: Additional Features

    X100 Series Quick Guide ADDITIONAL FEATURES X100C WIRELESS IP CUBE CAMERA X100T IP BODY CAMERA • Features White LEDs for 10m Night Vision • C/CS Mount Lens with Auto Iris Support • 4.0mm Lens for 50° viewing angle • Supplied with a 4.0mm lens as standard •...

  • Page 5: Minimum System Requirements

    X100 Series Quick Guide iii MINIMUM SYSTEM REQUIREMENTS The following are the minimum system requirements for the X100 Series IP Camera Range: Network Environment Wired Models Wireless Model (X100C, X104P) Network Interface: 10/100MBase-TX Ethernet 10/100MBase-TX Ethernet 802.11b/g or n WLAN Browser: Internet Explorer 6.0, Safari 5.0, FireFox 3.5 or later...

  • Page 6: Notes On Installation

    X100 Series Quick Guide iv NOTES ON INSTALLATION • Please unpack all boxes carefully and identify that all the parts are present. • Do not aim the camera at the sun or similar intense light. • Treat the camera with care.

  • Page 7: Install & Connect

    X100 Series Quick Guide 1.1 X100C WIRELESS IP CUBE CAMERA PACKAGE CONTENTS • X100C IP Camera • Wireless Antenna • Camera Bracket • Fixing Screws & Wall Plugs • 12V DC Power Adaptor • User’s Manual & Software CD IDENTIFY PARTS...
  • Page 8 X100 Series Quick Guide INSTALLATION The X100C IP Camera can be mounted on a Wall or Ceiling. It can also be desk mounted using the bracket supplied. For Wall or Ceiling mounting, make a hole where the camera is to be installed to insert the 12V DC Power Adaptor and LAN cable.

  • Page 9: X104P Wireless Pan Tilt Zoom Ip Camera

    X100 Series Quick Guide 1.2 X104P WIRELESS PAN TILT ZOOM IP CAMERA PACKAGE CONTENTS • X104P IP Camera • Fixing Screws & Wall Plugs • Wireless Antenna • 12V DC Power Adaptor • L-Bracket with 2x Screws • User’s Manual & Software CD...
  • Page 10 X100 Series Quick Guide INSTALLATION The X104P IP Camera can be mounted on a Wall or Ceiling using the L-Bracket provided. It is designed for internal use only. It can also be desk mounted as supplied. For Wall or Ceiling mounting, make a hole where the camera is to be installed to insert the 12V DC Power Adaptor and LAN cable.
  • Page 11 X100 Series Quick Guide Resetting your camera The Reset Button is used to restore the factory default settings. If you are experiencing problems with the IP camera, sometimes restarting the device will make the system revert back to a normal state.

  • Page 12: X100D Ip Dome Camera

    X100 Series Quick Guide 1.3 X100D IP DOME CAMERA PACKAGE CONTENTS • Power Cable with terminal connections • X100D IP Camera • Fixing Screws & Wall Plugs • User’s Manual & Software CD • 12V DC Power Adaptor IDENTIFY PARTS...
  • Page 13 X100 Series Quick Guide INSTALLATION Select a mounting position on a wall or ceiling. Rotate the dome housing anti-clockwise to remove the camera from the mounting base. Use the mounting base to mark up screw positions and make a hole in the wall or ceiling to insert the LAN cable and 12V DC Cable (if using Power over Ethernet, 12V DC Power is not required).
  • Page 14 The X100D camera is supplied with a 4.0mm board lens for 50° viewing angle. The lens can be manually replaced with an Xvision Megapixel Board Lens to achieve a different viewing angle. Any lens change should be made after you have connected the camera and have set up live viewing via your PC so that...
  • Page 15 Place spring on new lens before screwing back on to board mount Note: The following Xvision Megapixel lenses are compatible with the X100D IP camera: • XL010P-PRO (1.55mm Fixed Iris Megapixel Lens, for 135° viewing angle) • XL035P-PRO (3.5mm Fixed Iris Megapixel Lens, for 85° viewing angle) •...

  • Page 16: X100V Vandal Resistant Ip Dome Camera

    X100 Series Quick Guide 1.4 X100V VANDAL RESISTANT IP DOME CAMERA PACKAGE CONTENTS • Power Cable with terminal connections • X100V IP Camera • Side Exit Fitting • Fixing Screws • Stopper • Allen Key • 12V DC Power Adaptor •...
  • Page 17 X100 Series Quick Guide INSTALLATION Select a mounting position on a wall or ceiling. Decide whether the cables are to go through the dome base or via the side cable exit and block off the unused exit with the stopper.
  • Page 18 X100 Series Quick Guide Adjust the camera direction and angle of view as required using the camera bracket inside. - Make any lens (Zoom/Focus) adjustments after you have connected the camera & have setup live viewing via your PC. - Make the Zoom Adjustment by rotating the screw anticlockwise for NEAR adjustment and clockwise for FAR adjustment until you get the desired view.
  • Page 19 X100 Series Quick Guide Connect the 12V DC Power Adaptor to the Power Cable and attach the positive (+) to VCC12 and the negative (-) to GND as shown (if using POE this step is not required): VCC12 DIGITAL_IN Power Adaptor...
  • Page 20 X100 Series Quick Guide Resetting your camera The Reset Button is used to restore the factory default settings. If you are experiencing problems with the IP camera, sometimes restarting the device will make the system revert back to a normal state.

  • Page 21: X100B Ip Bullet Camera

    X100 Series Quick Guide 1.5 X100B IP BULLET CAMERA PACKAGE CONTENTS • X100B IP Camera with Sun/Rain Shield • Camera Bracket • Fixing Screws & Wall Plugs • 12V DC Power Adaptor • User’s Manual & Software CD IDENTIFY PARTS...
  • Page 22 X100 Series Quick Guide INSTALLATION Select a mounting position and make a hole where the camera is to be installed Use the screws and wall plugs supplied to fix the bracket on a wall or ceiling as shown. WALL MOUNT...
  • Page 23 X100 Series Quick Guide Alarm and RS485 Connections Grouping Cable Name (Colour) Connect to: DI (Green/White) Alarm Sensor Input DO (Orange/White) Alarm Output ALARM SENSOR (Optional) 12V DC (Brown/White) Alarm Output Power (12V DC 50mA Max) GND (Blue/White) Alarm Sensor Ground...

  • Page 24: X100T Ip Body Camera

    X100 Series Quick Guide 1.6 X100T IP BODY CAMERA PACKAGE CONTENTS • X100T IP Camera with Lens • CS Mount Lens Adaptor • Camera Mount with 2x screws • 12V DC Power Adaptor • Camera Bracket • User’s Manual & Software CD •...
  • Page 25 X100 Series Quick Guide INSTALLATION Select a mounting position on a wall or ceiling. Make a hole where the camera is to be installed to insert the LAN cable and 12V DC Cable (if using Power over Ethernet, 12V DC Power is not required).
  • Page 26 The X100T camera is supplied with a 4.0mm fixed lens for 50° viewing angle. The lens can be manually replaced with an Xvision Megapixel Varifocal or Fixed Lens to achieve a different viewing angle. Any lens change should be made after you have connected the camera and have set up live viewing via your PC so that the focus can be set correctly.
  • Page 27 X100 Series Quick Guide Note: The following Xvision Megapixel lenses are compatible with the X100T IP camera: • XL010M-PRO (1.55mm Fixed Iris Megapixel Lens, for 135° viewing angle) • XL040M-PRO (4.0mm Fixed Iris Megapixel Lens, for 64° viewing angle) •...

  • Page 28: X104S Vandal Resistant Ip Speed Dome

    X100 Series Quick Guide 1.7 X104S VANDAL RESISTANT IP SPEED DOME PACKAGE CONTENTS • X104S IP Camera • Allen Key • Ceiling Mount with 4x Screws • 12V DC Power Adaptor • Fixing Screws & Wall Plugs • User’s Manual & Software CD...
  • Page 29 X100 Series Quick Guide INSTALLATION Make a hole in the ceiling where the camera is to be installed. Use the screws and wall plugs supplied to fix the bracket on the ceiling. Hole to feed trailing lead through the ceiling...
  • Page 30 X100 Series Quick Guide 4 CAMERA INSTALLATION Lens Adjustment Make any lens (focus) adjustments after you have connected the camera and have setup live viewing via your PC. Focus Ring To adjust the lens, open the Dome Cover by turning it anti-clockwise and rotate the Focus Ring.

  • Page 31: X100Vs Video Server (Codec)

    X100 Series Quick Guide 1.8 X100VS VIDEO SERVER (CODEC) PACKAGE CONTENTS • Audio/Video Output Cable • X100VS Video Server • 12V DC Power Adaptor • Power Cable for External Camera • User’s Manual & Software CD • User’s Manual & Software CD...
  • Page 32 X100 Series Quick Guide INSTALLATION Attach Video lead from your analogue camera to the BNC Video Input - Ensure the analogue camera is powered Connect the LAN cable and 12V DC Cable to the Video Server (if using Power over Ethernet, 12V DC Power is not required).
  • Page 33 X100 Series Quick Guide Connecting an RS485 Zoom, Pan Tilt Zoom or Speed Dome The Video Server supports the following functions when connected to a compatible Zoom, Pan Tilt Zoom or Speed Dome: Pan Tilt Zoom, Set Presets Call Presets...

  • Page 34: Setup (Quick Guide)

    2.1 SETTING UP YOUR NETWORK WHAT YOU NEED Your X100 Series IP Camera(s) LAN cable and Connection Equipment such as a hub or router suiting your network environment - Use Cat5 STRAIGHT THROUGH cable to connect the IP Camera(s) to a network switch or hub.

  • Page 35: Search And Setup By Ipwizard Ii

    X100 Series Quick Guide 2.2 SEARCH AND SETUP BY IPWIZARD II SETTING UP THE IPWIZARD II ON YOUR PC Locate the IPWizard II Installer file inside the IPWizard II folder on the User Manual CD Double click the file and follow the on screen instructions to install the software.
  • Page 36 X100 Series Quick Guide CONFIGURE YOUR CAMERA’S NETWORK SETTINGS Click LAN to configure your IP camera with your network settings. - There are 2 options to set the IP address; Static IP or DHCP IP. Your option depends on how your network is setup.
  • Page 37 EDIT YOUR WIRELESS SETTINGS for X100C and X104P Wireless IP Cameras All other IP cameras in the X100 Series are WIRED ONLY and these settings cannot be applied to them (go to Step 10 on page 39 to continue with WIRED setup).
  • Page 38 X100 Series Quick Guide An information window will appear. Confirm your settings by clicking OK. - To change any details, click CANCEL and edit the information in the WIRELESS menu. The IPWizard II will begin configuring the camera to your specifications then prompt you to unplug the Ethernet cable to activate the wireless settings.
  • Page 39 X100 Series Quick Guide EXIT IPWIZARD II When you have finished, click EXIT to quit the program. You are now ready to access your IP Camera’s web configuration page where you can adjust the camera settings.

  • Page 40: Access Your Ip Camera On Your Web Browser

    X100 Series Quick Guide 2.3 ACCESS YOUR CAMERA ON YOUR WEB BROWSER Open your web browser Type in your camera’s IP address in the format: http://192.168.0.100 - If you have set up your own IP address, replace 192.168.0.100 with the new address.

  • Page 41: Appendix 1: How To Calibrate An Auto Iris Lens

    X100 Series Quick Guide APPENDIX 1: HOW TO CALIBRATE AN AUTO IRIS LENS - This information can also be found on page 61 of the Main User Manual located on the CD provided. This procedure applies if you are configuring the X100V, and optionally, the X100T (if you have replaced the standard lens with an Auto Iris lens).
  • Page 42 X100 Series Quick Guide In the PICTURE TAB, locate the setting marked AUTO IRIS.
 Click on the CALIBRATE button - A popup window will appear to show the progress of calibration. It may take a few minutes for the camera to calibrate the lens.

  • Page 43: Xvision Support

    X100 Series Quick Guide XVISION SUPPORT At Xvision we provide quality products that perform to the highest standards, while being simple to install and use. If you have any difficulties setting up or using your product please visit our support pages at www.xvision.com for assistance and for details of online and telephone support in your region.
  • Page 44 V1-2/2010-10...
