I N S T A L L A T I O N
T he el ec tri c c onnec ti on m ust onl y b e c arri ed out b y a qu al if i ed el ec tri c i an.
C A U T I O N S
• The maximum recommended ambient temperature is 104°F (40°C).
Do not use the fixture above this temperature.
• For added protection, mount the fixture in areas outside walking paths, seating areas, or
in areas were unauthorized personnel might reach the fixture.
• Before mounting the fixture to any surface, make sure the installation area can hold a
minimum point load of 10 times the weight of the fixture. (165 lbs / 75 kgs)
• Fixture installation must always be secured with a secondary safety attachment, such as
an appropriate safety cable.
• Never stand directly below the device when mounting, removing or servicing the fixture.
• Be sure the fixture is kept at least 0.5m (1.5 feet) away from any flammable materials
(decoration etc.).
P O W E R
120V 60Hz - ONLY (4) devices may be linked together for power.
Connect device number #5 to a different power source.
230V 50Hz - ONLY (8) devices may be linked together for power.
Connect device number #9 to a different power source.
10
L I N K I N G
