Touchstone™ TM402 Telephony Modem
User's Guide
Get ready to experience the Internet's express lane! Whether you're checking out
streaming media, downloading new software, checking your email, or talking with
friends on the phone, the Touchstone TM402 Telephony Modem brings it all to you
faster and more reliably. All while providing toll quality Voice over IP telephone ser-
vice. Some models even provide a Lithium-Ion battery backup to provide continued
telephone service during power outages.
The Touchstone Telephony Modem provides an Ethernet connection for use with ei-
ther a single computer or home/office Local Area Network (LAN). The Touchstone
Telephony Modem also provides a USB connection. You can connect two separate
computers at the same time using both of these connections. In addition, the
Touchstone Telephony Modem provides for up to two separate lines of telephone
service.
Installation is simple and your cable company will provide assistance to you for any
special requirements. The links below will provide more detailed instructions.
Safety Requirements
Getting Started
Battery Installation and Replacement (TM402G, TM402H, and TM402P models
only)
Installing and Connecting Your Telephony Modem
Installing the Telephony Modem USB Drivers
Configuring Your Ethernet Connection
Using the Telephony Modem
Troubleshooting
Glossary
Touchstone TM402 Telephony Modem User's Guide
1
