Capacities And Replacement Parts - E-Z-GO RXV Fleet Freedom Shuttle 2+2 Owner's Manual

OPERATION AND SERVICE INFORMATION
Read all of manual to become familiar with this vehicle. Pay attention to all NOTICES, CAUTIONS, WARNINGS and DANGERS.
B
REMARKS
Steering Assembly - excessive play, loose or missing
hardware
Tie Rods - excessive play, bent rods, loose or missing
hardware
Rear Axle - fluid level, oil leakage, noise, loose or
missing hardware
Rear Axle - drain & replace fluid
Rear Suspension - shock oil leakage, worn bushings,
loose or missing hardware
Front Suspension - strut oil leakage, excessive play in
hubs or kingpins, worn bushings, loose or missing
hardware
Front Wheel Alignment - unusual tire wear
Fuel Level
Fuel System - leaks at tank, cap, system lines for
cracks/deterioration, filters, pump
Fuel Filter
Spark Plug
Throttle/Governor Linkage - operation & governed
speed
Air Filter Element - check & replace as necessary
Drive Belt - cracks, frayed, excessive wear
**Initial oil change after 8 hours of run time.

CAPACITIES AND REPLACEMENT PARTS

FLUID
Fuel Tank
Engine Oil
Rear Axle Lubricant Oil SAE 30
Fig. 20 Capacities
Page 14
3
Fig. 19
QUANTITY
6.0 gal (22.5 liters) 87
Octane minimum
1.25 L (1.3 qt.)
1.5 L. (51 oz.)
Owner's Guide
3 3
3 3
3 3
3
3 3
C&A
3 3 3
3
3
ITEM
Oil Filter E-Z-GO P/N 607454
Air Filter E-Z-GO P/N 28463G01
Spark Plug NGK BPR2ES (E-Z-GO P/N 607462)
Starter/Gen. Belt E-Z-GO P/N 606138
Clutch Belt E-Z-GO P/N 606136
Fuse ATC 10A (E-Z-GO P/N 35212G07)
Headlight Bulb 894 (E-Z-GO P/N 74004G01)
Turn Signal Bulb 912-NA (E-Z-GO P/N 74005G01)
Tail Light Bulb 2057 (E-Z-GO P/N 604311)
Fig. 21 Replacement Parts
3 3
3 3
3 3
R
3 3
3 3
C&A C&A
3 3
3 3
R
R
3 3
3 3
3 3
PART NUMBER
