- Page 1 RM/TM-2030CL RMC/TMC-2030CL Digital Monochrome/Color Progressive Scan, Interline-Transfer CL Camera Document Version: E Document P/N: 10437...
- Page 3 The material contained in this manual consists of information that is proprietary to JAI Inc., and may only be used by the purchasers of the product. JAI, Inc. makes no warranty for the use of its product and assumes no responsibility for any errors which may appear or for damages resulting from the use of the information contained herein.
- Page 4 TM/TMC/RM/RMC-2030CL Disclaimer...
-
Page 5: Table Of Contents
TM/TMC/RM/RMC-2030CL Table of Contents Disclaimer Notice ....................iii Table of Contents ....................v List of Figures ....................... vii List of Tables ......................ix Introduction ..................... 1 Software Installation .................. 1 1.1.1 Before Installing Dual-Tap AccuPiXEL Series Camera-Control Software ....... 1 ... - Page 6 TM/TMC/RM/RMC-2030CL 5.2.3 Starting Pixel Configuration ................. 25 5.2.4 Sync and Data ..................26 5.2.5 Camera Functions ..................26 5.2.6 Interpolation Software ................26 5.2.7 Color Interpolation ................... 27 Dynamic Range Control ................27 ...
-
Page 7: Camera Model
TM/TMC/RM/RMC-2030CL List of Figures Figure 1. The Setup icon installs Dual Tap AccuPIXel v 2.6.x.x ..........2 Figure 2. AccuPIXel Setup screen ................2 Figure 3. The “Add or Remove Programs” utility can uninstall older software......2 ... - Page 8 TM/TMC/RM/RMC-2030CL Figure 51. Field Video Timing--Continuous Mode ............. 34 Figure 52. Change memory settings................38 Figure 53. Physical Dimensions .................. 41 Figure 54. Monochrome Response ................42 Figure 55. Color Response ..................42 ...
- Page 9 TM/TMC/RM/RMC-2030CL List of Tables Table 1 12-Pin Connector ..................18 Table 2 Connector and Pin-out Configurations ............. 19 Table 3 12-Pin Interface Pin-Outs ................21 Table 4 Scan Area Start Points ................24 ...
- Page 10 TM/TMC/RM/RMC-2030CL List of Tables...
-
Page 11: Introduction
1.1.2 Installing the Software To install the Dual-Tap AccuPiXEL series camera-control software, obtain the software from the JAI web site and run “Setup.exe.” The installer will direct you to install the application code. If dual tap software is already installed on your computer, uninstall the software using the steps in the Uninstall section. -
Page 12: Uninstalling The Software
TM/TMC/RM/RMC-2030CL Open the file. Double click on the JAI Inc. GigE 2.2.0.1 Install icon. Figure 1. The Setup icon installs Dual Tap AccuPIXel v 2.6.x.x Follow the Setup instructions. Figure 2. AccuPIXel Setup screen 1.1.3 Uninstalling the Software To uninstall the Dual-Tap AccuPiXEL series camera-control software from the control panel, follow the steps below. -
Page 13: Tm/Tmc-2030Cl Camera
TM/TMC/RM/RMC-2030CL TM/TMC-2030CL Camera Figure 4. Back of the TM/TMC-2030CL The camera must have all cables properly connected and any required adapters installed and configured to allow the software to perform the operations on the interface. Introduction... -
Page 14: Gui Features
TM/TMC/RM/RMC-2030CL GUI Features The following is a list of camera functions that PC serial commands can control. The Dual-Tap AccuPiXEL series Camera Link cameras use differential serial communication through the Camera Link connector on the rear panel of the camera. The interface shown here is for the TM/TMC 2030 CL cameras. Figure 5. -
Page 15: Operating The Control Software
TM/TMC/RM/RMC-2030CL Operating The Control Software 2.1.1 Exposure Control The TM-2030CL exposure control allows you to select Continuous or Trigger modes using the appropriate radio button. Notice that Continuous and Trigger mode offer slightly different menus. 2.1.1 (a) Continuous Mode Shutter Speed The Shutter Speed drop-down list box allows you to select the specific shutter speed for manual shutter and Async shutter. -
Page 16: Configuring Trigger Settings
TM/TMC/RM/RMC-2030CL Figure 8. To use Programmable shutter speed, select Programmable. 2.1.1 (d) Expo (lines) The “Expo (lines”) selection of the Exposure Control frame determines how long the shutter remains open, since a certain amount of time is allotted to expose each line. A minimum of one line of pixels must be exposed. -
Page 17: Gain Control
TM/TMC/RM/RMC-2030CL The maximum trigger frequency in this mode is equal to 1/ (transfer time of two frames + exposure time of the first image). The minimum active period of the external trigger is 10 pixel clocks (250ns) 2.1.3 Gain Control 2.1.3 (a) Gain Gain controls the brightness of an image. -
Page 18: Tap Selection
TM/TMC/RM/RMC-2030CL Checking the “Auto Offset” check box causes the camera to automatically adjust the offset. The camera continues to adjust the offset unless the user unchecks the auto offset; in that case the offset is left off. When the offset is changed the new setting does not show in the interface. It is necessary to click on the “Report”... -
Page 19: Lut (Look-Up Table)
TM/TMC/RM/RMC-2030CL Figure 16. Image Pre-Processing is activated by checking “Enable Blemish Compensation”. 2.1.7 LUT (Look-Up Table) The Knee Control box allows you to set your own knee value to each LUT. See “LUT (Look-Up Table)” on page 28 (section 5.3.1) for more detail regarding the knee control. 2.1.7 (a) Positive or Negative LUT Selection The LUT control panel allows you to select the positive or negative LUT. -
Page 20: Rx Tx Report Frame
TM/TMC/RM/RMC-2030CL Figure 19. Gamma.45 imitates human eye sensitivity when creating an image. The knee setting allows two adjustments in the light gathering configuration of the LUT to permit the camera to correct images as they are captured. It is possible to set knees on any of the drop down settings by clicking on the existing curve and moving it to the desired configuration. -
Page 21: Main Menu: "File
TM/TMC/RM/RMC-2030CL Main Menu: “File” 2.2.1 Load and Save Page Click on the File menu and choose Load Page to load a saved set of camera parameters. The 1 slot contains the power up default settings. Figure 22. Load Page 2.2.1 (a) Save Page Click on the File menu and choose Save Page to change a saved set of camera parameters. -
Page 22: Main Menu Option
Main Menu Option Click on the “Option” menu and choose “Password” to gain access to load page 0 of the camera parameters. Contact JAI Inc. at 1-800-445-5444 for password access. The password allows access to the EEPROM to rewrite factory default settings. -
Page 23: Main Menu "Connectivity
TM/TMC/RM/RMC-2030CL Figure 27. Video output order 2.3.2 Main Menu “Connectivity” Click on the “Connectivity” menu to view the buffer size. Some frame grabbers have a small buffer size and require a special communication algorithm. Use the “Receive Buffer Size” menu to set the buffer size. If you have trouble communicating with the camera, then select the “Receive buffer is small”... -
Page 24: Figure 31. Control Software Version
TM/TMC/RM/RMC-2030CL 2.3.3 (c) About Control Software From the main menu, select “About” and click “About Control Software” to check the software information. Figure 31. Control Software Version GUI Features... -
Page 25: Hardware Introduction
For more information, please see Section 5.5 on page 28. Unless otherwise stated, all information in this manual applies to the TM-2030CL series; the TM-2030CL, TMC-2030CL and their RoHS compliant RM-2030CL and RMC-2030CL. The TM-2030CL output is available with either 8-bit, 10-bit or 12-bit processing. - Page 26 TM/TMC/RM/RMC-2030CL • Asynchronous reset The TM-2030CL captures async reset images and provides single-shot video output with single FDV (frame data valid). This makes it simpler for an ordinary frame grabber to capture the asynchronous reset images. The TM- 2030CL’s asynchronous reset is flexible and accepts external horizontal drive (HD) for phase locking. When the VINIT (5V) pulse is applied to CC1, it resets the camera's scanning and purging of the CCD.
-
Page 27: Installation
4.1.2 Components When you receive your TM-2030CL camera from JAI Inc., the contents of the shipping box should include the camera and a document download card. If either of these items are missing, please contact your JAI Inc. representative immediately. The document download card includes instructions and web locations for downloading the datasheet, manual, and camera-control software. -
Page 28: Connector Pin Configurations
TM/TMC/RM/RMC-2030CL 4.2.2 Connector Pin Configurations 4.2.2 (a) 12-Pin Connector The TM-2030CL has a 12-pin Hirose connector for power input as shown in Figure 32. Figure 32. 12-Pin Connector Pinouts Pin #1 is Ground and pin #2 is +12V DC. Table 7 shows the pin-out table. Table 1 12-Pin Connector Description... -
Page 29: Camera Link Cable
The 26CL-02-26 cable assembly has been standardized as the Camera Link cable. This cable has a 26-pin connector on both ends. This is a straight-through cable and the pin-out configuration is shown in Table 2 on page 19. Contact JAI for cable lengths other than 2 meters. Installation... -
Page 30: Power Supplies And Power Cable Setup
4.2.4 (b) JAI Inc. Power Cables If you are using JAI Inc. power cables such as the 12P-02S, please refer to the 12-pin connector pinout diagram below. The cable pin-out diagram is shown in Figure 36. The color-coded leads use Gray for Ground and Yellow for +12V. -
Page 31: Attaching The Camera Lens
TM/TMC/RM/RMC-2030CL Figure 36. 12P-02S Interface Cable (optional) Table 3 12-Pin Interface Pin-Outs 12P-02S Interface Cable Pin# Lead Color Function Pin# Lead Color Function Gray Black coax TTL IN (EXT_VD) Yellow +12V DC White coax shield TTL OUT (STROBE) Red coax shield GND(analog) White coax TTL IN (EXT_HD) -
Page 32: Figure 37. Back Focus Set-Screw Locations
TM/TMC/RM/RMC-2030CL There should be an obvious need to refocus the lens before attempting to change the back focus. This is a very exacting task. Some cameras have been returned to the factory to reset the back focus after failed attempts to change the focus by customers. -
Page 33: Operation
TM/TMC/RM/RMC-2030CL Operation Progressive Scanning Standard TV-system scanning is 525 lines interlace scanning as specified in the RS-170 protocol. Every other horizontal line (odd lines and even lines) is scanned at a 60Hz rate per field, and the scanning is completed with two fields (one frame) at 30Hz rate. -
Page 34: Bayer Color Filter (Color Versions)
5.2.1 Color Filter Array JAI Inc. AccuPiXEL cameras use Bayer CFA (color filter array) as their standard primary color filter. This filter provides the most popular color interpolation supported by numerous software suppliers. The digital format allows the camera to output accurate pixel data, including the color information. When the data is stored in the frame buffer of a frame grabber or computer, the color information is easily manipulated to restore the original color images. -
Page 35: Starting Pixel Configuration
R/G start or G/R start, as well as G/B start and B/G start. Once the correct scanning is configured, the rest of the interpolation is exactly the same. Contact JAI Inc. for further information regarding CCD manufacturers. -
Page 36: Sync And Data
TM/TMC/RM/RMC-2030CL 5.2.4 Sync and Data The individual color data is exactly the same as the pixel data. This means that the timing relationships of the color cameras are also the same as of the monochrome cameras. For a detailed timing chart, please refer to each monochrome camera’s data sheet and manual. The following diagram is an example of the TMC-2030CL default mode. -
Page 37: Color Interpolation
3 x 3 interpolation, 2 x 2 interpolation, color matrix, white balance capability, and so on. All AccuPiXEL color cameras are carefully designed for maximum color performance. JAI Inc. strongly suggests that you use digital output for the best performance. -
Page 38: Programmable Look-Up Table (Lut) And Knee Control
TM/TMC/RM/RMC-2030CL noise, and the operating clock speed. In general, the level of the 20 MHz pixel clock CCD at room temperature is around 20 to 50 electrons. The maximum capacity of CCD charges is limited by the well capacity at saturation. -
Page 39: Asynchronous Programmable Exposure Mode
TM/TMC/RM/RMC-2030CL Because the external trigger is randomly applied, the new image charge may overlap with the previous image. To prevent an existing charge accumulation from interfering with a new image, most users set up the application in a dark area and depend on a strobe light for illumination. From the time the external trigger activates until the transfer gate turns off, about 9.5 video lines are available for integration;... -
Page 40: Pulse Width Control Mode
TM/TMC/RM/RMC-2030CL • If the exposure time is less than one frame time, the maximum trigger frequency is equal to 1/1 frame time. • If the exposure time is longer than one frame time, the maximum trigger frequency is equal to 1/exposure time. -
Page 41: Particle Imaging Velocimetry Fixed Exposure Mode
TM/TMC/RM/RMC-2030CL Figure 46. Pulse Width Control Trigger 5.5.5 Particle Imaging Velocimetry Fixed Exposure Mode In Particle Imaging Velocimetry (PIV) Fixed Exposure Mode, when an external trigger is applied, the first time exposure starts the same as PWC mode does. It lasts a very short period (8μs). The second time exposure starts during the transferring time of the first image accumulated in the first exposure time. -
Page 42: Pwc Piv Mode
TM/TMC/RM/RMC-2030CL 5.5.6 PWC PIV Mode The PWC PIV is based on PIV Fixed Exposure. In this mode, the first time exposure is controlled by the pulse width of the external trigger, which is similar to PWC mode. The real exposure time of the first image is equal to the pulse width of the external trigger. -
Page 43: Camera Timing Charts
TM/TMC/RM/RMC-2030CL Camera Timing Charts Figure 49. Camera Timing Chart Figure 50. Digital Data Output Order for Configuration Operation... -
Page 44: Figure 51. Field Video Timing--Continuous Mode
TM/TMC/RM/RMC-2030CL Figure 51. Field Video Timing--Continuous Mode Operation... -
Page 45: Camera Serial Commands
TM/TMC/RM/RMC-2030CL Camera Serial Commands You can control the C series cameras by serial command either using RS-232 or Camera Link. The Start character is always “:” and the End character is always <CR> (return). For example, to set Asynchronous Pulse Width Mode, send the command :ASH=9<CR>... -
Page 46: Table 7 Command Responses
TM/TMC/RM/RMC-2030CL Command Parameter End of Cmd Ack. Response Description Dual Tap Digital Video Output Order :VDO <cr> :o[VD][X]<cr> Set Dual Tap Digital Video Output Order (X = A, B, C, ?) (A <--<--, B <---->, C <<----, ? Inquire video output order) Image Pre-processing :BLC= <cr>... - Page 47 TM/TMC/RM/RMC-2030CL Command Parameter End of Cmd Description Bit 4 Shutter Mode 0 00=Continuous Preset Shutter 01=Trigger Preset Shutter 10=Trigger Programmable Shutter Bit 5 Shutter Mode 1 11=Continuous Programmable Shutter Bit 6 Data Depth 0 00=8bit 01=10bit Bit 7 Data Depth 1 10=12bit Byte 11 Function Flag 2...
-
Page 48: Troubleshooting
Following are troubleshooting tips for common problems. In general, the problems listed in this section are solved by following these instructions. If there is no solution listed to the problem you are encountering, contact a JAI Inc. representative. 7.1.1 Symptom: No Video Remedies: Check that the following are properly connected and operational. -
Page 49: Information And Support Resources
TM/TMC/RM/RMC-2030CL 7.1.6 Information and Support Resources For further information and support: North American Technical Support Phone 408-383-0300 E-Mail: camerasupport@jai.com European Technical Support Phone: +45 4457 8916 E-Mail: camerasupport@jai.com Japan/Asia Technical Support Phone +81 45 440 0154 E-Mail: tsh@jai.com Mail: JAI Inc. -
Page 50: Appendix
TM/TMC/RM/RMC-2030CL Appendix Specifications Table 8 TM-2030CL Camera Specifications Table Feature TM-2030CL Sensor 1" progressive scan interline transfer CCD Active Area 14.2mm x 8.0mm Active Pixels 1920 (H) x 1080 (V) Cell Size 7.4μm x 7.4μm Readout Mode 1920 (H) x 1080 (V) @ 32 Hz (dual tap) or (Active Pixels) 16 Hz (single tap) selectable Sync... -
Page 51: Tm-2030Cl Physical Dimensions
TM/TMC/RM/RMC-2030CL 8.1.1 TM-2030CL Physical Dimensions Figure 53. Physical Dimensions Caution: When mounting the camera to any fixture, do not use screws that extend more than 5 mm into the camera housing to avoid possible damage to the internal circuitry. For attaching the tripod mounting plate, only the supplied screws should be used. -
Page 52: Spectral Response
TM/TMC/RM/RMC-2030CL 8.1.2 Spectral Response Figure 54. Monochrome Response Figure 55. Color Response Appendix... - Page 54 Europe, Middle East & Africa Phone +45 4457 8888 Fax +45 4491 3252 Asia Pacific Phone +81 45 440 0154 Fax +81 45 440 0166 Americas Phone (Toll-Free) 1 800 445-5444 Phone +1 408 383-0301 www.jai.com...
