- Page 1 Owner’s Manual Model No. 1640855 - Assembly - Operation - Adjustments - Parts - Warranty CAUTION: Read and understand this manual before operating unit Retain For Future Reference...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions…………………………………………………………….. 2 Before you begin …………………….………………………………………………….. 4 Hardware list …………………………………………………………………………….. 5 Assembly instructions…………….……………………………………………………… 6 Treadmill operation ……………………………………………………………………… 9 Operation of the monitor ……………………………………….………………..………. 10 Folding Instructions ………………………………………………………………………..14 Part list ………………………………………………………………………………………15 Parts diagram ………………………………………………………………………………19 Belt adjustment ……………………………………………………………………………. 20 General Maintenance.……………….………………………………………….…………... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INFORMATION THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY READ ALL INSTRUCTIONS BEFORE USING THIS TREADMILL ▲CAUTION: Before starting any exercise program, it is recommended that you consult your physician. ▲WARNING: Connect this unit to a properly grounded outlet only. ▲DANGER: To reduce the risk of electric shock, always unplug the treadmill from the electrical outlet immediately after using and before cleaning. - Page 4 14. Handicapped individuals should have medical approval and close supervision when using this treadmill. 15. Do not place hands or feet under the treadmill. Always keep hands and legs off of the treadmill when others are using it. 16. Never turn on treadmill while standing on treadbelt. Always hold the handrails while using the treadmill.
-
Page 5: Before You Begin
Before you begin. Thank you for purchasing our product. Even though we go to great efforts to ensure the quality of each product we produce, occasional errors and /or omissions do occur. In any event should you find this product to have either a defective or a missing part please contact us for a replacement. This product has been designed for home use only. -
Page 6: Hardware List
HARDWARE LIST #148. #94. Ø8 × 1.5T Ø5/16" × 19 × 1.5T #88. 5 × 16m/m Split Washer (4pcs) Curved Washer (2pcs) Tapping Screw (4pcs) #90. 5/16" × 3/4" #93. 5/16" × 15m/m Button Head Socket Bolt #95. Button Head Socket Bolt M5 ×... -
Page 7: Assembly Instructions
ASSEMBLY INSTRUCTIONS ■ STEP 1 Remove all the parts from the carton and lay the main base frame on a flat level surface. ■ STEP 2 Slide the right frame base cover (42) on the right upright (4). Connect the lower computer cable (39) to the computer extension cable (38). Slide the left frame base cover (43) on the left upright (5). - Page 8 ■ STEP 3 It will take two people for this step. Insert the right upright (4) into the Frame Base (2). Secure with two speed nut clips (132), four 5/16" × 15m/m button head socket bolts (93) and one Ø5/16" × 19 × 1.5T Curved Washer (94) using the combination M5 allen wrench &...
- Page 9 ■ STEP 5 Connect the Computer Cable (Middle)(38) with the Computer Cable (Upper)(37). Connect the Speed/Hand Pulse Complex W/Cable (127) with the Speed/Hand Pulse Complex (53). Connect the Incline/Hand Pulse Complex W/Cable (128) with the Incline/Hand Pulse Complex (54). Connect Connecting Cable (Upper) (152) and Connecting Cable (Lower) (131) ■...
-
Page 10: Treadmill Operation
TREADMILL OPERATION Your treadmill features a walking belt coated with a lubricant. IMPORTANT: Never apply silicone spray or other substances to the walking belt or walking board. Such substances will deteriorate the walking belt and cause excessive wear. How to plug in the power cord. GROUNDING INSTRUCTIONS. -
Page 11: Operation Of The Monitor
Operation of the monitor GETTING STARTED: ▲CAUTION: Before operating the console, read the following precautions: • Do not stand on the walking belt when turning on the treadmill • Always wear the safety key. Pulling the safety key will stop tread-belt movement. •... -
Page 12: Quick Start
TO OPERATE TREADMILL ▲CAUTION: To avoid injury, hold onto the handrails while mounting and dismounting the treadmill. Hold onto the handrails and place feet on siderails before starting. Step onto the walking belt only a slowest speed. Always hold on to a handrail or hand bar while making control changes (incline, speed, etc.). -
Page 13: Preset Programs
INCLINE ▲：To increase the incline level with increment of 0.5. INCLINE ▼：To decrease the incline level with 0.5 less for each press. QUICK SPEED：To change the speed rapidly. Quick speed buttons are 2, 4, 6, 8 and 10 KMH / MPH. -
Page 14: Error Messages
USER1, USER2: User define modes Press USER to switch the USER1 and USER2. A>The program may start directly with all preset value parameters. The program pattern may be stored at the end of the training. B>You may also press ENTER to set age, weight, time and continue to program 18 segments of speed by using FAST/SLOW buttons and then 18 segments of incline levels by using UP/DOWN buttons. -
Page 15: Folding Instructions
FOLDING AND MOVING YOUR TREADMILL Before folding the treadmill, ensure that the treadmill is at its lowest incline position. Turn the power switch off, located on the front of the motor cover and unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45lbs) in order to raise and lower the treadmill. To decrease the possibility of injury, bend your legs and keep your back straight while you are raising or lowering your treadmill. -
Page 16: Part List
PARTS LIST PART NO DESCRIPTION Q'TY 085501 Main Frame 085502 Frame Base 085503 Incline Bracket 085504 Right Upright 085505 Left Upright 085506 Console Support 085509 Outer Slide 085510 Inner Slide 085511 Locking Knob 085512 Top Frame Cover 085513 Bottom Frame Cover 085514 Motor Bracket 085516... - Page 17 PART NO DESCRIPTION Q'TY 085540-09 Top Fan Cover 40~9 085540-10 Bottom Fan Cover 40~10 085540-11 Fan Assembly 40~11 085540-12 500m/m_Safety Key 40~12 085540-15 Speaker Grill Anchor 40~15 085540-16 600m/m_Speaker W/Cable 40~16 085540-17 Amplifier Controller 40~17 085540-18 300m/m_Amplifier Cable 40~18 085540-22 300m/m_Earphone socket with cable 40~22 085540-24...
- Page 18 PART NO DESCRIPTION Q'TY 085572 M8 × 80m/m_Socket Head Cap Bolt 085573 M8 × 30m/m_Flat Head Countersink Bolt 085574 1/2" × 8T_Nyloc Nut 085575 3/8" × 7T_Nyloc Nut 085576 5/16" × 6T_Nyloc Nut 085577 M8 × 8T_Nyloc Nut 085578 3/8" × 7T_Nut 085579 3 ×...
- Page 19 PART NO DESCRIPTION Q'TY 0855141 Ø4.5 × Ø25 × 15L_Rubber Foot Pad 0855142 Incline Motor Cover 0855144 3/8" × 2-1/4"_Flat Head Socket Bolt 0855145 Foot Rail Back Plate 0855146 4 × 19m/m_Sheet Metal Screw 0855147 4 × 6m/m_Phillips Head Trilobular Screw 0855148 Ø8 ×...
-
Page 20: Parts Diagram
PARTS DIAGRAM CUSTOMER SERVICE 1-888-707-1880 Maurice Pincoffs Canada© 2012... -
Page 21: Belt Adjustment
BELT ADJUSTMENTS: Treadbelt Tension Adjustment - Belt tension is not critical for most users. It is very important for joggers and runners in order to provide a smooth, steady running surface. Adjustment must be made from the right side of the rear roller in order to adjust tension with the 6 mm Allen wrench provided in the parts package. - Page 22 WARRANTY. BELT / DECK LUBRICATION: Do not lubricate with other than Xterra approved lubricant. Your treadmill comes with one tube of lubricant and extra tubes can be ordered directly from Xterra. There are commercially available lube kits, but the only one currently approved by Xterra is Lube-N-Walk.
-
Page 23: General Maintenance
are walking. This should be about 18 inches from the motor cover, but you may want to walk on the treadmill before loosening the belt to note where your feet land on the belt. If you mostly run on the treadmill, the spot where your feet land may be different from walking. -
Page 24: Reset Switch Resetting
RESET SWITCH RESETTING If your treadmill looses power or will not start, check the reset switch located on the front of the motor cover. If the white tab of the reset switch is not showing then the reset switch has not been tripped. - Page 25 12.0). Adjust the top speed setting and press Enter o The display will show a number for the max incline setting (12 for 1640355, 15 for 1640855), then press Start to begin calibration. o The belt will start automatically and will adjust speeds between low and high.
-
Page 26: Service Check List
If an extension cord is required it should be as short as possible and heavy duty 16 gauge minimum. Low household voltage. Contact an electrician or your Xterra dealer. A minimum of 110 volt AC current is required. High belt/deck friction. See General Maintenance Treadmill belt stops quickly/suddenly when section on lubrication. -
Page 27: Manufacturer's Limited Warranty
12 months from the date of purchase. All other obligations or liabilities, including liability for consequential damages are hereby excluded. All of the parts for the Xterra Treadmill, shown in figure can be ordered from: MAURICE PINCOFFS CANADA INC., 6050 Don Murie Street, Niagara Falls, Ontario 0B3.
