Daikin D-Series Service Manual page 58

Si12-619A
Floor / Ceiling Suspended Dual Type
Model
Rated Capacity
Front Panel Color
m³/min
Air Flow Rates
(cfm)
Type
Fan Motor Output
Speed
Air Direction Control
Air Filter
Running Current (Rated)
Power Consumption (Rated)
Power Factor
Temperature Control
Dimensions (H×W×D)
Packaged Dimensions (H×W×D)
Weight
Gross Weight
Operation
H/M/L/SL
Sound
Heat Insulation
Liquid
Piping Connection Gas
Drain
Drawing No.
Model
Rated Capacity
Front Panel Color
m³/min
Air Flow Rates
(cfm)
Type
Fan Motor Output
Speed
Air Direction Control
Air Filter
Running Current (Rated)
Power Consumption (Rated)
Power Factor
Temperature Control
Dimensions (H×W×D)
Packaged Dimensions (H×W×D)
Weight
Gross Weight
Operation
H/M/L/SL
Sound
Sound Power H
Heat Insulation
Liquid
Piping Connection Gas
Drain
Drawing No.
Specifications
FLXS25BVMA
Cooling
2.5kW Class
Almond White
H 7.6 (268)
M 6.8 (240)
L 6.0 (212)
SL 5.2 (184)
Sirocco Fan
W
Steps 5 Steps, Quiet, Auto
Right, Left, Horizontal, Downward
Removable-Washable-Mildew Proof
A 0.32
W 70
% 95.1
Microcomputer Control
mm 490×1,050×200
mm 280×1,100×566
kg
kg
dBA 37/34/31/28
Both Liquid and Gas Pipes
φ
mm
φ
mm
φ
mm 18.0
3D046600
FLXS50BVMA
Cooling
5.0kW Class
Almond White
H 11.4 (403)
M 10.0 (353)
L 8.5 (300)
SL 7.5 (265)
Sirocco Fan
W
Steps 5 Steps, Quiet, Auto
Right, Left, Horizontal, Downward
Removable-Washable-Mildew Proof
A 0.47-0.45-0.43/0.47-0.45
W 96
% 92.8-92.8-93.0/92.8-92.8
Microcomputer Control
mm 490×1,050×200
mm 280×1,100×566
kg
kg
dBA 47/43/39/36
dBA 63
Both Liquid and Gas Pipes
φ
mm
φ
mm 12.7
φ
mm 18.0
3D055049
Heating
9.2 (325)
8.3 (293)
7.4 (261)
6.6 (233)
34
0.34
74
94.6
16
22
37/34/31/29
6.4
9.5
Heating
12.1 (427)
9.8 (346)
7.5 (265)
6.8 (240)
34
0.47-0.45-0.43/0.47-0.45 0.49-0.47-0.45/0.49-0.47
96
92.8-92.8-93.0/92.8-92.8 90.9-90.7-90.7/90.9-90.7
17
24
46/41/35/33
62
6.4
Specifications
FLXS35BVMA
Cooling Heating
3.5kW Class
Almond White
8.6 (304) 9.8 (346)
7.6 (268) 8.9 (314)
6.6 (233) 8.0 (282)
5.6 (198) 7.2 (254)
Sirocco Fan
34
5 Steps, Quiet, Auto
Right, Left, Horizontal, Downward
Removable-Washable-Mildew Proof
0.36 0.36
78 78
94.2 94.2
Microcomputer Control
490×1,050×200
280×1,100×566
16
22
38/35/32/29 39/36/33/30
Both Liquid and Gas Pipes
φ
6.4
φ
9.5
φ
18.0
3D046601
50Hz 220-230-240V / 60Hz 220-230V
FLXS60BVMA
Cooling Heating
5.7kW Class
Almond White
12.0 (424) 12.8 (452)
10.7 (378) 10.6 (374)
9.3 (328) 8.4 (297)
8.3 (293) 7.5 (265)
Sirocco Fan
34
5 Steps, Quiet, Auto
Right, Left, Horizontal, Downward
Removable-Washable-Mildew Proof
0.47-0.45-0.43/0.47-0.45
98 96
92.8-92.8-93.0/92.8-92.8
Microcomputer Control
490×1,050×200
280×1,100×566
17
24
48/45/41/39 47/42/37/34
64 63
Both Liquid and Gas Pipes
φ
6.4
φ
12.7
φ
18.0
3D055050
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
50Hz 230V
45
