INSTALLATION
MANUAL
AIR COOLED, DUCTED
SPLIT TYPE AIR-CONDITIONERS
(D & E SERIES)
MODELS
R22 Cooling only
FDM75DXV1
RC75D(G)XY1
FDM100DXV1 RC100D(G)XY1
FD125DXY1
RC125D(G)XY1
FD150DXY1
RC150D(G)XY1
2FD150DXY1
RC75D(G)XY1 x 2
2FD200DXY1
RC100D(G)XY1 x 2
2FG250DXY1
RC125D(G)XY1 x 2
2FG300DXY1
RC150D(G)XY1 x 2
4FG400DXY1
RC100D(G)XY1 x 4
4FG500DXY1
RC125D(G)XY1 x 4
R22 Heatpump
FDYM75DXV1 RCY75E(G)XY1
FDYM100DXV1 RCY100E(G)XY1
FDY125EXY1
RCY125E(G)XY1
FDY150EXY1
RCY150E(G)XY1
2FDY150EXY1 RCY75E(G)XY1 x 2
2FDY200EXY1 RCY100E(G)XY1 x 2
2FGY250EXY1 RCY125E(G)XY1 x 2
2FGY300EXY1 RCY150E(G)XY1 x 2
3FGY300EXY1 RCY100E(G)XY1 x 3
RCY100E(G)XY1
3FGY350EXY1
RCY125E(G)XY1 x 2
4FGY400EXY1 RCY100E(G)XY1 x 4
3FGY450EXY1 RCY150E(G)XY1 x 3
4FGY500EXY1 RCY125E(G)XY1 x 4
4FGY600EXY1 RCY150E(G)XY1 x 4
R407C Cooling only
FDMP75DXV1
RCP75D(G)XY1
FDMP100DXV1 RCP100D(G)XY1
FDP125DXY1
RCP125D(G)XY1
FDP150DXY1
RCP150D(G)XY1
2FDP150DXY1
RCP75D(G)XY1 x 2
2FDP200DXY1
RCP100D(G)XY1 x 2
2FGP250DXY1
RCP125D(G)XY1 x 2
2FGP300DXY1
RCP150D(G)XY1 x 2
4FGP400DXY1
RCP100D(G)XY1 x 4
4FGP500DXY1
RCP125D(G)XY1 x 4
R407C Heatpump
FDYMP75DXV1 RCYP75E(G)XY1
FDYMP100DXV1 RCYP100E(G)XY1
FDYP125EXY1
RCYP125E(G)XY1
FDYP150EXY1
RCYP150E(G)XY1
2FDYP150EXY1 RCYP75E(G)XY1 x 2
2FDYP200EXY1 RCYP100E(G)XY1 x 2
2FGYP250EXY1 RCYP125E(G)XY1 x 2
2FGYP300EXY1 RCYP150E(G)XY1 x 2
3FGYP300EXY1 RCYP100E(G)XY1 x 3
RCYP100E(G)XY1
3FGYP350EXY1
RCYP125E(G)XY1 x 2
4FGYP400EXY1 RCYP100E(G)XY1 x 4
3FGYP450EXY1 RCYP150E(G)XY1 x 3
4FGYP500EXY1 RCYP125E(G)XY1 x 4
4FGYP600EXY1 RCYP150E(G)XY1 x 4
Installation Manual
Split Type Air Conditioner
Manuel D'installation
Climatiseurs Split System
Installationshandbuch
Doppelfunktions-Klimagerät
Manuale Di Installazione
Condizionatore Split A
Manual De Instalación
Equipo de air Acondicionado
de tipo Dividido de
Руководство по установке
разделить Кондиционер
воздуха типа
Kurulum kılavuzu
Split Tipi Klima
IM-CC&SB-D/ER-0412(0)-Daikin
Part No.: R08019037636
English
Français
Deutsch
Italiano
Español
Русский
Türkçe
Advertisement
Table of Contents
Related Manuals for Daikin FDM75DXV1
Summary of Contents for Daikin FDM75DXV1
- Page 1 English Split Type Air Conditioner Manuel D’installation Français Climatiseurs Split System MODELS Installationshandbuch R407C Cooling only R22 Cooling only Deutsch Doppelfunktions-Klimagerät FDMP75DXV1 RCP75D(G)XY1 FDM75DXV1 RC75D(G)XY1 FDMP100DXV1 RCP100D(G)XY1 FDM100DXV1 RC100D(G)XY1 FDP125DXY1 RCP125D(G)XY1 FD125DXY1 RC125D(G)XY1 Manuale Di Installazione Italiano FDP150DXY1 RCP150D(G)XY1 FD150DXY1...
-
Page 3: Outline And Dimensions
OUTLINE AND DIMENSIONS FD(Y)M(P) 75/100D All dimensions are in mm Dimension Model 1120 1264 1370 100D 1349 1493 1599 Dimension Model 100D... - Page 4 FD(P) 125/150D FDY(P) 125/150E All dimensions are in mm Dimension Model 125D/125E 1526 1754 1654 1794 150D/150E 1805 2033 1933 2073 Dimension Model 125D/125E 1009 150D/150E 1009...
- Page 5 2FD(P) 150D/2FDY(P) 150E All dimensions are in mm Dimension Model 150D/150E 1805 2033 1933 2073 Dimension Model 150D/150E 1014...
- Page 6 2FG(P) 200/250/300D All dimensions are in mm Dimension Model 200D 1064 1209 1169 1089 1260 1113 250D 1226 1298 1258 1178 1129 1349 1202 1011 300D 1226 1501 1461 1381 1129 1552 1405 1214 Dimension Model 200D 1324 250D 1486 300D 1486...
- Page 7 4FG(P) 400/500D All dimensions are in mm Dimension Model 400D 1691 1651 1571 1742 1596 1405 1462 500D 2047 2007 1927 2098 1952 1172 1760 1462 Dimension Model 400D 1367 1090 1722 1175 500D 1367 1090 1722 1175...
- Page 8 2FGY(P) 200E All dimensions are in mm NOTE: FOR HORIZONTAL AIR DISCHARGE Dimension Model 200E 1624 1834 1794 1040 Dimension Model 200E 1894...
- Page 9 2FGY(P) 250/300E 3FGY(P) 300/350/450E 4FGY(P) 400/500E All dimensions are in mm NOTE: FOR VERTICAL AIR DISCHARGE Dimension Model 250/300E 1826 1636 973 1231 1259 1766 1866 560 350E 2082 1852 973 1451 1259 2022 2122 560 400/450/500E 2234 2004 1271 1451 1556 2174 2274 694 Dimension Model 250/300E...
- Page 10 4FGY(P) 600E All dimensions are in mm NOTE: FOR VERTICAL AIR DISCHARGE Dimension Model 600E 2174 2004 2234 2274 1679 1978 Dimension Model 600E 1775 1758 1883 1905...
- Page 11 RC(P) 75/100/125/150D RCY(P) 75/100/125/150E All dimensions are in mm Dimension Model 75/100D 1041 75/100E 125D 1083 1041 150E 150D 1083 1047 1142 150E...
-
Page 12: Safety Precautions
INSTALLATION MANUAL This manual provides the procedures of installation to ensure a safe and good standard of operation for the air conditioner unit. Special adjustment may be necessary to suit local requirements. Before using your air conditioner, please read this instruction manual carefully and keep it for future reference. This appliance is intended to be used by expert or trained users in shops, in light industry and on farms, or for commercial use by lay persons. -
Page 13: Installation Of The Indoor Unit
INSTALLATION OF THE INDOOR UNIT FG(Y)M(P) 75~100D Mounting Ensure that the overhead supports are strong enough to hold the unit’s weight. Position hanger rods and check for alignment with the unit. Check that hangers are secure and that the base of fan-coil unit is level in the two horizontal directions, taking into account the gradient recommended for drainage flow as shown. -
Page 14: Installation Of The Outdoor Unit
INSTALLATION OF THE OUTDOOR UNIT Location For Installation Install the outdoor unit in such way that air distributed by When two or more outdoor units are installed in a location, the outdoor unit cannot be drawn in again (as in the case they must be positioned such that one unit will not be taking of short circuit of discharge air). - Page 15 Piping Works And Flaring Technique TXV bulb placement in relation to suction line size • Do not use contaminated or damaged copper tubing. If any piping, evaporator or condenser had been exposed or had been opened for 15 seconds or more, the system must be vacuumed.
-
Page 16: Electrical Connection
ELECTRICAL CONNECTION IMPORTANT: * These values are for information only, they should be checked and selected to comply with the local and/or national codes and regulations. They are also subjected to the type of installation and size of conductors. ** The appropriate voltage range should be checked with data label on the unit. Cooling Unit FDM(P) 75/100D COMP... - Page 17 Model Indoor FD(P) 125D FD(P) 150D Outdoor RC(P) 125D RC(P) 150D Voltage range** Indoor 380-415V/3PH/50Hz+ ! Outdoor Power supply cable size* /mm² A) Indoor B) Outdoor C) Total Number of conductors A) Indoor B) Outdoor Interconnection cable size* / mm² Number of conductors Recommended time delay fuse* /A A) Indoor...
- Page 18 Heat Pump FDMY(P) 75/100E Outdoor Unit LP HP DS DS COMP Terminal Block Power Supply Cable Indoor Unit To Indoor Control Board Terminal Block There must be an all pole disconnection in the supply mains with a contact COMP separation of at least 3mm. Model Indoor FDMY(P) 75D...
- Page 19 Model Indoor FDY(P) 125E FDY(P) 150E Outdoor RCY(P) 125E RCY(P) 150E Voltage range** Indoor 380-415V/3PH/50Hz+ ! Outdoor Power supply cable size* /mm² A) Indoor B) Outdoor C) Total Number of conductors A) Indoor B) Outdoor Interconnection cable size* / mm² Number of conductors Recommended time delay fuse* /A A) Indoor...
-
Page 20: Special Precautions When Dealing With R407C Unit
• All wires must be fi rmly connected. • Make sure all the wire do not touch the refrigerant pipings, compressor or any moving parts. • The connecting wire between the indoor unit and the outdoor unit must be clamped by using provided cord anchorage. •... -
Page 21: Vacuuming And Charging
VACUUMING AND CHARGING Vacuuming is necessary to eliminate all moisture and air from the system. The series II Outdoor Unit is provided with flare valve fittings. Vacuuming The Piping And The Indoor Unit Except for the outdoor unit which is pre-charged with Refrigerant Piping refrigerant, the indoor unit and the refrigerant connection Allen key... -
Page 22: Additional Charge
ADDITIONAL CHARGE The refrigerant is pre-charge in the outdoor unit. If the piping length is less than 7.5m, then additional charge after vacuuming is not necessary. When the piping length is more than 7.5m, use the table below. R407C Liquid pipe OD Additional charge kg/m Additional charge kg/m 3/8"... - Page 23 Invert cylinder without dip-pipe Dip-pipe Liquid withdrawal ! CAUTION • Manifold Gauge will show cylinder pressure rather than suction pressure if the cylinder valve and Manifold valve “A” are both open. There are many ways of charging liquid in a “controlled manner” into the suction side:- Use valve A on the manifold gauge set Use the valve on the refrigerant cylinder...
-
Page 24: Standard Operating Conditions
STANDARD OPERATING CONDITIONS Heating Cooling Temperature Ts °C Th °C Temperature Ts °C Th °C Minimum indoor temperature Minimum indoor temperature Maximum indoor temperature Maximum indoor temperature Minimum outdoor temperature Minimum outdoor temperature Maximum outdoor temperature Maximum outdoor temperature Ts: Dry bulb temperature. Th: Wet bulb temperature. -
Page 25: Service And Maintenance
SERVICE AND MAINTENANCE Service Parts Maintenance Procedures Period Indoor air filter Remove any dust adhering to the filter by using a vacuum cleaner At least once every 2 weeks. or wash in lukewarm water (below 40°C) with a neutral cleaning detergent. - Page 26 MEMO...
- Page 28 • In the event that there is any conflict in the interpretation of this manual and any translation of the same in any language, the English version of this manual shall prevail. • The manufacturer reserves the right to revise any of the specification and design contain herein at any time without prior notification.
