8.5.6 500-39-30 / 31 1U 12 KEY PANEL WITH LOUDSPEAKER

This panel provides more basic facilities than the 500-30 range. It does not have LCD
displays and only provides connection to the matrix, audio I/O and the test port at the rear.
An installation specification is given below.
Dimensions
Mains Input
Current Consumption
8.5.6.1 500-39-30 Connector Pin Out
Matrix – D9 Fixed Plug
Pin Function
1 NC (Screen)
2 Data Out-
3 Data In-
4 Audio Out-
5 Audio In-
6 Data Out +
7 Data In +
8 Audio Out +
9 Audio In +
Audio I/O – D15 Fixed Socket
Pin Function
1 Slave Mic Input
2 +15V Out (for slave mic panel)
3 Clean Mic Out +
4 Ext CUT Input (for slave mic panel)
5 Chassis Ground
6 No connection
7 External Input to LS Amp -
8 Matrix Audio Input to Panel / parallel output -
9 Ext Mic Cut output (to slave panel)
10 -15V Out (for Slave mic panel)
11 Clean Mic Out -
12 Mic Ground
13 Loudspeaker Output
14 External Input to LS Amp +
15 Matrix Audio Input to Panel / parallel output +
NB 15V supplies are also used to derive 12V for panel. (Thermally Fused @ 0.7A)
The 500-39-31 panel includes an additional expansion connector, logic GPIO signals and
footswitch connector in the same format as the 500-3x-3x series expansion panels. It is only
available to special order. See section 8.5.2.2 for connector details.
Trilogy Communications Limited
Commander Installation Guide
485mm wide x 44.5mm high x 150mm deep
(excluding connectors) 200m approx. (including
mating connectors)
19" x 1RU rack mounting
90 – 260 V ac, 50-60Hz
150mA @ 90V ac, 50mA @ 250V ac.
Test– D9 Fixed Socket
Pin Function
1 Analyse Input
2 Enable Remote Boot
3 Ground
4 Transputer Link Out +
5 Transputer Link In +
6 Error signal Out
7 Reset In
8 Transputer Link Out-
9 Transputer Link In-
Issue 9.1
Headset - 5 Pin XLR Fixed
Socket (front panel)
Pin Function
1 Mic IN (Screen)
2 Mic IN
3 Headset Gnd
4 Headset Out
5 Headset Out
Notes
Line level, un-balanced
NOT protected!
Line level, balanced, pair with 11
Parallel function to front panel Cut
Switch. Ground to activate
Line level, balanced, pair with 14
Line level, balanced, pair with 15
Normally grounded. O/P is open
circuit when front panel cut selected.
NOT protected
Line level, balanced, pair with 3
8 ohm loudspeaker
Line level, balanced, pair with 7
Line level, balanced, pair with 8
Page 75 of 81
