8.3.5 BLACK BOX IC114A PCMCIA SERIAL ADAPTOR CARD.

This adaptor card may be provided with single frame Commander systems, fitted with the
current 500-02-12 Talkback Controller. It provides full RS422 communication at 38.4kBaud.
The adaptor is supplied with installation instructions and software on 3.5" disk. Follow the
instructions carefully, taking care to install the system drivers on the PC first. Following a
successful installation, the adaptor will appear on the system toolbar (adjacent to the clock)
as a PCMCIA resource. Double click the PC card icon and the dialogue box below will
appear.
Trilogy Communications Limited
Commander Installation Guide
Issue 9.1
The adaptor card now appears
on the taskbar, showing that
COM2 has been allocated as a
resource attached to the serial
adaptor.
