5.10 500-33-00 / 500-45-00 / 500-46-00 RANGE
Although offering differing types and numbers of switches and displays, these panels share
the same electronics and connectivity.
• 500-33-00 32 way lever key
• 500-45-00 8 way push button
• 500-46-00 10 button, LC key.

5.10.1 SPECIFICATION

Dimensions
Mains Input
Current Consumption

5.10.2 CONNECTIONS

Matrix – RJ-45 fixed socket on panel
RJ-45 Function
Pin
1 Panel Data out +
2 Panel Data out -
3 Panel Data In +
6 Panel Data In -
5 Panel Audio out +
4 Panel Audio out -
7 Panel Audio in +
8 Panel Audio in -
Cable Screen
Headset - 5 Pin XLR Fixed Socket (front
panel)
Pin Function
1 Mic IN (Screen)
2 Mic IN
3 Headset Gnd
4 Headset Out
5 Headset Out
Page 48 of 81
Commander Installation Guide
o 500-33-00
485mm wide x 88.9mm high x 80mm deep (approx. including
PSU and mating connectors).
19" x 2RU rack mounting
o 500-45-00 / 500-46-00
485mm wide x 44.5mm high x 80mm deep (approx. including
PSU and mating connectors).
19" x 1RU rack mounting
90 – 250 V ac, 50-60Hz
150mA @ 90V, 50mA @ 250V
Pair
1
Pair
2
Pair
3
Pair
4
Issue 9.1
Foot Switch - D9 Fixed Socket
Pin Function
1 Foot Switch Input
2 No Connection
3 Chassis Ground
4 Reserved
5 Reserved
6 Ground
7 Reserved
8 Reserved
9 Reserved
