500-40-0X Series Expansion Panels - Trilogy Communications Commander Installation Manual

8.5.4 500-40-0X SERIES EXPANSION PANELS

Control Panels may be linked together to provide additional facilities at one operating
position. Additional level controls (RENs) or switches may be added. Alternatively, two
standard panels from the 500-30 series may be linked together and will only utilise a single
matrix port.
The following detail refers to expansion panel types:
• 500-40-00
• 500-40-01
• 500-40-02
500-40-04
•
An installation specification is given below.
Dimensions
Mains Input
Current Consumption
8.5.4.1 Connector Pin Out
Expansion In - D9 Fixed Socket
Pin Function
1 Analyse Input
2 Enable Remote Boot
3 Ground
4 Transputer Link Out +
5 Transputer Link In +
6 Error signal Out
7 Reset In
8 Transputer Link Out-
9 Transputer Link In-
Test Port– D9 Fixed Socket
Pin Function
1 Analyse Input
2 Enable Remote Boot
3 Ground
4 Transputer Link Out +
5 Transputer Link In +
6 Error signal in
7 Reset Out
8 Transputer Link Out-
9 Transputer Link In-
Trilogy Communications Limited
Commander Installation Guide
8 way encoder panel
12 way encoder panel
15 key switch panel
32 way encoder panel
485mm wide x 44.5mm high x 100mm deep
(excluding connectors) 150mm deep (maximum
including mating connectors)
19" x 1RU rack mounting
90 – 260 V ac, 50-60Hz
150mA @ 90V ac, 50mA @ 250V ac.
Issue 9.1
Expansion Out– D9 Fixed Socket
Pin Function
1 Analyse Input
2 Enable Remote Boot
3 Ground
4 Transputer Link Out +
5 Transputer Link In +
6 Error signal in
7 Reset Out
8 Transputer Link Out-
9 Transputer Link In-
