8.5.4.4 500-3x-3x Series Expansion panel interconnection cables
Type A (max. length 10 metre)
D9 Free Plug - Function
Pin
4 Transputer
Data out +
8 Transputer
Data out -
5 Transputer
Data In +
9 Transputer
Data In -
3 Ground
Type B (max length 10 metres)
D9 Free Plug - Function
Pin
4 Transputer
Data out +
8 Transputer
Data out -
5 Transputer
Data In +
9 Transputer
Data In -
3 Ground

8.5.5 CONNECTING VIA STRUCTURED CABLING

All control panel types may be connected to the matrix by Category 5 structured cabling
systems. Suitable adaptors are available from most electronic component distributors. The
RS part numbers are listed below.
Panel Connection: RJ45 to D9 socket. RS 818-700
Matrix Connection: RJ45 to D9 plug. RS 818-693
As supplied, these adaptors require the pins to be inserted into the D type housing. Use the
following table as a guide. The colour codes may not be correct for other brands.
D9 pin RJ 45 pin
1 No connection
2 2
3 6
4 4
5 8
6 1
7 3
8 5
9 7
Page 74 of 81
Commander Installation Guide
Function
Pair 1 Transputer
Data in +
Transputer
Data in -
Pair 2 Transputer
Data out +
Transputer
Data out -
Ground
Function
Pair 1 Transputer
Data in +
Transputer
Data in -
Pair 2 Transputer
Data out +
Transputer
Data out -
Ground
Colour (see above)
No connection
Yellow
Brown
Red
Blue
Black
Orange
Green
Grey
Issue 9.1
D9 Free Plug -
Pin
4
8
5
9
3
D9 Free Plug -
Pin
5
9
4
8
3
