Audio I/O – D15 Fixed Socket
Pin Function
1 Slave Mic Input
2 +15V Out (for slave mic panel)
3 Clean Mic Out +
4 Ext CUT Input (for slave mic panel)
5 Chassis Ground
6 No connection
7 External Input to LS Amp -
8 Matrix Audio Input to Panel / parallel output -
9 Ext Mic Cut output (to slave panel)
10 -15V Out (for Slave mic panel)
11 Clean Mic Out -
12 Mic Ground
13 Loudspeaker Output
14 External Input to LS Amp +
15 Matrix Audio Input to Panel / parallel output +
NB 15V supplies are also used to derive 12V for panel. (Thermally Fused @ 0.7A)

8.5.3 500-30 SERIES DIP SWITCH SETTINGS

Within the panel a series of DIP switches determine the correct panel type. These are
factory set and are included for reference in section 10.1
A further set of DIP switches is user accessible at the top side of the panel and control the
action of the front panel CUT switch. The factory default is shown in the table below.
Cut Switch Action
No action
Changeover to HSet MIC (default)
LS cut
Changeover to HSet MIC and LS cut
MIC cut
Changeover to HSet MIC and MIC cut
LS cut and MIC cut
Everything
Page 70 of 81
Commander Installation Guide
Notes
Line level, un-balanced
NOT protected!
Line level, balanced, pair with 11
Parallel function to front panel Cut
Switch. Ground to activate
Line level, balanced, pair with 14
Line level, balanced, pair with 15
Normally grounded. O/P is open
circuit when front panel cut selected.
NOT protected
Line level, balanced, pair with 3
8 ohm loudspeaker
Line level, balanced, pair with 7
Line level, balanced, pair with 8
DIP 1 DIP 2
OFF OFF
ON OFF
OFF ON
ON ON
OFF OFF
ON OFF
OFF ON
ON ON
Issue 9.1
DIP 3
OFF
OFF
OFF
OFF
ON
ON
ON
ON
